2018 Ford E Series Cutaway towing a vehicle

E-Series. The leader in commercial van capability.

Ford E-Series is the popular choice for Class 3–4 cutaway vans covering an extensive range of business and recreational uses — emergency service, commercial trades, bus and shuttle transport, motorhomes. They’re offered in the E-350 single rear wheel model, followed by the E-350/E-450 versions with dual rear wheels and higher GVWRs for handling the broad range of heavy-duty applications. All E-Series cutaways feature a comfortable cab built on a rugged full frame.
2018 Ford Super Duty E 350 with single rear wheels for basic cutaway chassis capability

E-350 Super Duty® SRW Cutaway

The E-350 Cutaway with single rear-wheel delivers all the power and capability needed for a wide range of commercial and recreational applications. It’s powered by a standard 6.8L Triton® V10 or available 6.2L flex-fuel V8. It has a GVWR of 10,050 lbs. (4,558 kg) (138- and 158-inch wheelbases) and a max payload rating of 5,230 lbs. (2,372 kg) (138-inch wheelbase).20
2018 Ford E 350 Super Duty with dual rear wheels for mid level cutaway chassis capability

E-350 Super Duty® DRW Cutaway

The E-350 with dual rear-wheels offers mid-range capacities in cutaway chassis available in three wheelbases: 138-, 158- and 176-inch. GVWR’s range from 11,500 to 12,500 lbs. (5,216 kg to 5,669 kg), with payload ratings from 6,280 to 7,340 lbs. (2,848 kg - 3,329 kg).20 The E-350 DRW is powered by a standard 6.8L Triton® V10 or an available 6.2L flex-fuel V8. The 151-litre fuel tank is standard for both the 6.8L and 6.2L engines on the E-350, and the 208-litre fuel tank is available for both.

High end 2018 Ford E 450 Super Duty DRW cutaway chassis capacity

E-450 Super Duty® DRW Cutaway

The E-450 with dual rear-wheels delivers high-end capability in cutaway chassis available in 158- and 176-inch wheelbases. GVWR’s range from 14,000 to 14,500 lbs., with payload ratings from 8,610 to 9,090 lbs. (3,905 kg to 4,123 kg). If you’re into towing heavy loads, the E-450 DRW has a maximum GCWR of 22,000 lbs. (9,979 kg). Power is supplied by a standard 6.8L Triton® V10 or an available 6.2L flex-fuel V8. The 208-litre fuel tank is standard for both the 6.8L and 6.2L engines on the E-450, and the 151-litre fuel tank is optional for both.
2018 Ford E-Series Cutaway maximum towing a vehicle

10,000-lb. (4,535 kg) Towing Capacity

With their full frame construction and standard V10 muscle, E-Series Cutaway models have an impressive towing capacity up to 10,000 lbs. (4,535 kg)20*. Plus GCWRs from 13,000 lbs. (5,896 kg) (E-350) to 22,000 lbs. (9,979 kg) (E-450). Add the convenience of available power or manually operated telescoping mirrors. Also, there’s an available factory-integrated trailer brake controller (TBC) that synchronizes the vehicle and trailer brakes for seamless operation. What’s more, the Ford TorqShift® six-speed automatic transmission has an integrated driver-selectable tow-haul mode that automatically compensates for altitude, grade and load conditions.

*Based on use or upfit.

2018 Ford E Series Cutaway with trailer tow mirrors

Available Telescoping Trailer Tow Mirrors

Trailers come in different lengths and widths. So it makes good sense to equip your vehicle with the available telescoping trailer tow mirrors that accommodate whatever type and size of trailer you’re towing. These mirrors come in either power or manual telescoping adjustment, and provide adjustable flat glass and a manual convex spotter mirror.

Factory-installed fully integrated trailer brake controller on the 2018 Ford E Series Cutaway

Available Factory-Installed Integrated Trailer Brake Controller (TBC)

E-Series Cutaway offers an available factory-installed, fully integrated trailer brake controller (TBC) with no installation hassles or aftermarket worries. Integrated with the anti-lock brakes, TBC synchronizes vehicle and trailer brakes for seamless braking, even with the heaviest loads. The Ford TBC offers the advantage of verified compatibility with trailers (one to four axles) utilizing electrically actuated drum brakes and certain electric- over-hydraulic (EOH) drum or disc brakes.

2018 Ford E-Series Cutaway steering wheel

Safety Features

Full frame construction provides a solid foundation for vehicle integrity. And for passenger protection, among the safety features are front airbags8 for the driver and front passenger, four-wheel anti-lock brakes to help you maintain steering control and come to a straight stop, plus available Traction Control System when road conditions are less than ideal. E-Series also comes with a standard Tire Pressure Monitoring System (TPMS) – for SRW models only – to help you make sure your tires are always inflated to their proper level.*

* Excluding spare tire.

U.S. Model Shown.
