2022 FORD F-650/F-750
BUILT FORD TOUGH® FROM ANY ANGLE
BUILT FORD TOUGH® FROM THE GROUND UP
POWER TO GET THE JOB DONE
CLASS-EXCLUSIVE* 7.3L V8 GAS ENGINEThe class-exclusive 7.3L V8 gas engine has an output of 350 hp and torque of 468 lbs. –ft. @ 3,900 rpm.20 This engine has the largest displacement in its class and features an overhead valve architecture that generates power low in the rev range to help get heavier loads moving sooner and with greater confidence. It also features a variable-displacement oil pump, extra-large main bearings, forged steel crankshaft for durability and piston cooling jets to help manage temperatures under heavy load. Ford remains the only OEM in this segment to make our own transmission and engine. ...lessU.S. Model Shown with Available Exterior Appearance Group.
*Class 6–7 Conventional Chassis Cabs based on Ford segmentation.
FORD 6.7L POWER STROKE® V8 TURBO DIESEL ENGINEThe 6.7L Power Stroke® V8 Turbo Diesel engine offers standard 270/700 as well as optional 300/725 and 330/750 power ratings (horsepower/torque).20 The unique inverse-flow design locates the turbocharger between the cylinder heads and the top of the block, with the exhaust manifold inboard and close to the turbo, for faster air displacement and greater power. The driver-activated engine exhaust braking restricts exhaust flow to create back pressure for seamless braking and reduced brake wear on downhill grades. ...lessU.S. Model Shown with Available Exterior Appearance Group.
FORD TORQSHIFT® HD 6-SPEED AUTOMATIC TRANSMISSIONThe Ford TorqShift® HD 6-speed automatic transmission is specially designed with a three-plate/two-stage torque converter and gearsets strengthened with extra pinion gears to handle the heavy demands of the V8 turbo diesel and V8 gas engines. The SelectShift® feature has two modes: Progressive Range Select that limits the range of gears to lock out overdrive, plus Full Manual control. Another feature is Tow/Haul. On an uphill, it selects the gear that minimizes gear hunting; on a downhill, it prevents upshifting and an increase in speed, reducing reliance on brake pressure to slow down. And the TorqShift® offers the available Live-Drive Power Takeoff provision with stationary and mobile modes. ...less
HARDWORKING FROM THE INSIDE OUT
LIVE-DRIVE POWER TAKEOFF (PTO) PROVISION WITH STATIONARY AND MOBILE MODES
U.S. Model Shown.
*Requires aftermarket Power Takeoff accessory.
The 2022 Ford F-650 and F-750 Medium Duty trucks are equipped with a variety of technologies to help you feel comfortable and in control. This includes features like Automatic Headlamps10 which are standard on all models and Hill Start Assist10*, while the available Driver-Assist Technology Package includes Automatic Emergency Braking118, Forward Collision Warning10, Lane Departure Warning10, Auto High-Beam Headlamps10 and Adaptive Cruise Control10**. Ford F-650/F-750 Driver-Assist Technologies10 are designed to help you be aware and alert you on the road ahead.
*Not available on Tractor models. Requires Hydraulic Brakes.
**Available only on F-650 and F-750 models with Air Brakes.
HILL START ASSIST
AUTO HIGH-BEAM HEADLAMPS
AUTOMATIC EMERGENCY BRAKING
LANE DEPARTURE WARNING
FORWARD COLLISION WARNING WITH BRAKE SUPPORT
ADAPTIVE CRUISE CONTROL
COMMERCIAL VEHICLE CENTRE DEALERS
CLEAN, EASY UPFITTING
F-650/F-750 trucks feature a work-ready frame developed with leading upfitters to accommodate most vocational bodies. This collaboration resulted in components such as fuel tanks, battery boxes and diesel exhaust fluid reservoirs located under the cab. Choose from 36 standard clean CA offerings ranging from 72 to 207" (1,829 to 5,258 mm).
U.S. Model Shown with Available Exterior Appearance Group....less
