2021 Ford® Bronco Sport Big Bend SUV

Exterior Features

Appearance

Standard

Lower Bodyside Cladding – Moulded-in-Colour, Black
Flip-Up Rear Glass Open image overlay for Flip-Up Rear Glass
Safari-Style Roof Open image overlay for Safari-Style Roof
Manual Liftgate
Door Handles – Moulded-in-Colour, Black
Beltline Moulding – Black
Upper Window Moulding – Black
Daytime Running Lamps (DRL)
LED Fog Lamps Open image overlay for LED Fog Lamps
LED Taillamps
17" Carbonized Grey-Painted High Gloss Aluminum Wheels Open image overlay for 17" Carbonized Grey-Painted High Gloss Aluminum Wheels
Grille – Carbonized Grey with Moulded in White Bronco Badge Open image overlay for Grille – Carbonized Grey with Moulded in White Bronco Badge
Active Grille Shutters
Mirrors, Sideview – Power Glass, Manual-Fold, Black Finish
Mirrors, Sideview – Heated Glass
Roof Rack Side Rails

Optional

Splash Guards – Front and Rear
18" Ebony Black-Painted Machined-Face Aluminum Wheels (64M) Open image overlay for 18" Ebony Black-Painted Machined-Face Aluminum Wheels (64M)
Roof-Rail Crossbars
Rapid Red Metallic Tinted Clearcoat
Alto Blue Metallic Tinted Clearcoat

Windows & Glass

Standard

Rain-Sensing Wipers (Front Only) Open image overlay for Rain-Sensing Wipers (Front Only)
Privacy Glass – 2nd-Row Side and Liftgate
Rear Fixed-Intermittent/Continuous Wiper/Washer
Windshield Wiper De-Icer

Interior Features

Climate

Standard

Electronic Automatic Temperature Control

Comfort and Convenience

Standard

Intelligent Access with Push-Button Start Open image overlay for Intelligent Access with Push-Button Start
Remote Start System Open image overlay for Remote Start System
Message Centre and Trip Computer
4.2'' Instrument Cluster
Carpeted Floor Mats, 1st-Row
Rubberized Cargo Floor Open image overlay for Rubberized Cargo Floor
Rear Seat – Rubberized Back Protector
Pre-Collision Assist with Automatic Emergency Braking (AEB)
Lane-Keeping System
Blind Spot Information System (BLIS^® ) with Cross-Traffic Alert
Cupholders, (8)
Driver's Side Footrest
Coat Hooks, 2nd-Row (2)
Grab Handles – Front Passenger, 2nd-Row (2)
Compass
Illuminated Visor Vanity Mirrors (Driver and Front Passenger)
Outside Temperature Display
Zippered Pockets (front driver/passenger seat back) with MOLLE Strap System Open image overlay for Zippered Pockets (front driver/passenger seat back) with MOLLE Strap System
Front and Rear Map Lights
Auto-Dimming Rearview Mirror
Powerpoints – 12V
Powerpoints – USB (Type C + Type A) Open image overlay for Powerpoints – USB (Type C + Type A)
Rotary Gear Shift Dial
Terrain Management System (TMS) with 5 G.O.A.T. Modes^™ (Goes Over Any Type of Terrain)
Front Row: Centre Floor Console Armrest, Glove Box, Media Bin, Overhead Console with Sunglasses Storage
Power Windows with Driver's Front One-Touch Down (Driver's Only)
Flood Lights – Adjustable (2), Liftgate Open image overlay for Flood Lights – Adjustable (2), Liftgate
Cargo Tie-Down Carabiner Hooks Open image overlay for Cargo Tie-Down Carabiner Hooks
Steering Wheel with Bronco Badge, Cruise and Audio Controls, Manual Tilt and Telescoping Steering Column

Optional

Cargo Mat
Floor Liners, Front and Rear (with Carpet Mats)
Power Moonroof Open image overlay for Power Moonroof
Floor Liners, Front and Rear (without Carpet Mats)
Cargo Area Management System (Shelf/Divider/Table) Open image overlay for Cargo Area Management System (Shelf/Divider/Table)
Leather-Wrapped Steering Wheel

Entertainment Systems

Standard

AM/FM stereo with 6 Speakers
8" LCD Capacitive Touchscreen in Centre Stack with Swipe Capability
AppLink^™
911 Assist^®
SiriusXM^®
SYNC^® 3 with Apple Carplay^™ and Android Auto^™ Compatibility
FordPass Connect^™ (Wi-Fi Hotspot)

Optional

Voice-Activated Touchscreen Navigation System with Pinch-to-Zoom Capability, SiriusXM^® Traffic and Travel Link

Seating

Standard

Cloth (Easy to Clean) Seating Surfaces Open image overlay for Cloth (Easy to Clean) Seating Surfaces
Heated Front Seats Open image overlay for Heated Front Seats
8-Way Power Driver Seat
4-Way Manual Passenger Seat
2nd-Row, 60/40 Split-Fold-Flat Seats

Packages

Power and Handling

Safety

Standard

Personal Safety System^™
Driver and Front Row Passenger Dual-Stage Airbags
Driver Knee Airbag
Front Seat-Mounted Side-Impact Airbags
Safety Canopy^® System – 1st- and 2nd-Row Safety Canopy^® Side Curtain with Rollover Sensor
Lower Anchors and Tether Anchors for Children (LATCH)
SOS Post-Crash Alert System^™
Head Restraints
Front Row Height Adjustable Retractable Safety Belts with Three-Point on All Five (5) Seating Positions
Mini Spare Tire
Tire Pressure Monitoring System (TPMS)
Belt-Minder^® (1st- and 2nd-Row)

Security

Standard

Flip Keys, Two (2), with Remote Control Lock/Unlock and Panic Button
SecuriCode^™ Keyless Entry Keypad Open image overlay for SecuriCode^™ Keyless Entry Keypad
MyKey^®
SecuriLock^® Passive Anti-Theft System
Perimeter Alarm
LED Headlamps with LED Signature Lighting
Auto High-Beam Headlamps
Rear View Camera with Washer
AdvanceTrac^® with RSC^® (Roll Stability Control^™ )
Post-Collision Braking

Specifications

Exterior Dimensions

Switch to Imperial Units Switch to Metric Units

Drive System	4x4
	mm
Wheelbase	2,670
Length	4,387
Height - Excluding Options (2.0L/1.5L)	1,814 / 1,783
Width - Including Mirrors	2,088
Width - Excluding Mirrors	1,887
Width - Mirrors Folded	1,938
Track - Front	1,610
Track - Rear	1,595

Drive System	4x4
	in.
Wheelbase	105.1
Length	172.7
Height - Excluding Options (2.0L/1.5L)	71.4 / 70.2
Width - Including Mirrors	82.2
Width - Excluding Mirrors	74.3
Width - Mirrors Folded	76.3
Track - Front	63.4
Track - Rear	62.8

Interior Dimensions

Switch to Imperial Units Switch to Metric Units

Head Room	mm
First Row (without Moonroof)	1,054
First Row (with Moonroof)	993
Second Row	1,059
Leg Room
First Row (maximum)	1,077
Second Row	937
Hip Room
First Row	1,402
Second Row	1,356
Shoulder Room
First Row	1,455
Second Row	1,412

Head Room	in.
First Row (without Moonroof)	41.5
First Row (with Moonroof)	39.1
Second Row	41.7
Leg Room
First Row (maximum)	42.4
Second Row	36.9
Hip Room
First Row	55.2
Second Row	53.4
Shoulder Room
First Row	57.3
Second Row	55.6

Capacities: Passengers, Luggage, Fuel

Switch to Imperial Units Switch to Metric Units

Maximum Seating Capacity	5
Standard Seating Capacity	5
	L (unless otherwise noted)
Passenger Volume - Base Roof	2,993
Passenger Volume - Moonroof	2,897
Cargo Volume Behind 1st Row (w/o Moonroof)	1,846 / 1,702
Cargo Volume Behind 2nd Row (w/Moonroof)	920 / 833
Fuel capacity	61
Base Curb Weight - 1.5L EcoBoost^®	1,568 kg
Base Curb Weight - 2.0L EcoBoost^®	1,684 kg

Maximum Seating Capacity	5
Standard Seating Capacity	5
	cu. ft. (unless otherwise noted)
Passenger Volume - Base Roof	105.7
Passenger Volume - Moonroof	102.3
Cargo Volume Behind 1st Row (w/o Moonroof)	65.2 / 60.1
Cargo Volume Behind 2nd Row (w/Moonroof)	32.5 / 29.4
Fuel capacity	16 gal.
Base Curb Weight - 1.5L EcoBoost^®	3,457 lbs.
Base Curb Weight - 2.0L EcoBoost^®	3,713 lbs.

Engine Specifications

Switch to Imperial Units Switch to Metric Units

	Base/Big Bend/Outer Banks	Badlands
Engine type	1.5L EcoBoost^® Engine with Auto Start-Stop Technology	2.0L EcoBoost^® Engine with Auto Start-Stop Technology
	1.5L Ti-VCT GTDI I-3	2.0L Ti-VCT GTDI I-3
Drive type	4x4	Advanced 4x4 with Twin-Clutch Rear Drive Unit
Exhaust	Dual Exhaust	Dual Exhaust
Transmission type	8-speed Automatic Transmission	8-speed Automatic Transmission; SelectShift^® with Paddle shifters
Horsepower** (SAE net@rpm)	181 @ 6,000 rpm	250 @ 5,500 rpm
Torque** (lb.-ft.@rpm)	190 @ 3,000 rpm	277 @ 3,000 rpm
Compression ratio	11.0:1	10.0:1
Valve lifters	Direct Injection and Port Fuel Injection	Direct acting mechanical bucket
Engine block material	Aluminum	Aluminum
Cylinder head material	Aluminum	Aluminum
Induction system	Single Turbocharged	Single Twin-Scroll Turbocharged
Fuel delivery	Direct injection	Direct injection
Fuel (minimum)	Regular unleaded	Regular unleaded
Fuel Consumption *Fuel consumption ratings based on Government of Canada approved test methods. Actual fuel consumption will vary.	Est. 9.3 L/100km city, 8.3 L/100km highway, 8.9 L/100km combined*	Est. 11.1 L/100km city, 8.9 L/100km highway, 10.1 L/100km combined*
**Horsepower and torque ratings based on premium fuel per SAE J1349 standard. Your results may vary.

	Base/Big Bend/Outer Banks	Badlands
Engine type	1.5L EcoBoost^® Engine with Auto Start-Stop Technology	2.0L EcoBoost^® Engine with Auto Start-Stop Technology
	1.5L Ti-VCT GTDI I-3	2.0L Ti-VCT GTDI I-3
Drive type	4x4	Advanced 4x4 with Twin-Clutch Rear Drive Unit
Exhaust	Dual Exhaust	Dual Exhaust
Transmission type	8-speed Automatic Transmission	8-speed Automatic Transmission; SelectShift^® with Paddle shifters
Horsepower** (SAE net@rpm)	181 @ 6,000 rpm	250 @ 5,500 rpm
Torque** (lb.-ft.@rpm)	190 @ 3,000 rpm	277 @ 3,000 rpm
Compression ratio	11.0:1	10.0:1
Valve lifters	Direct Injection and Port Fuel Injection	Direct acting mechanical bucket
Engine block material	Aluminum	Aluminum
Cylinder head material	Aluminum	Aluminum
Induction system	Single Turbocharged	Single Twin-Scroll Turbocharged
Fuel delivery	Direct injection	Direct injection
Fuel (minimum)	Regular unleaded	Regular unleaded
Fuel Consumption *Fuel consumption ratings based on Government of Canada approved test methods. Actual fuel consumption will vary.	30 city/ 34 hwy / 32 combined (mpg-lmp)*	25 city/ 32 hwy / 28 combined (mpg-lmp)*
**Horsepower and torque ratings based on premium fuel per SAE J1349 standard. Your results may vary.

Towing

Switch to Imperial Units Switch to Metric Units

Model	Big Bend/Outer Banks	Badlands
Engine	1.5L EcoBoost^® Engine with Auto Start-Stop Technology	2.0L EcoBoost^® Engine with Auto Start-Stop Technology
Available Features	Class II Trailer Tow Package w/ Trailer Sway Control	Class II Trailer Tow Package w/ Trailer Sway Control
Max. Trailer Weight	2,000 lbs.	2,200 lbs.

Model	Big Bend/Outer Banks	Badlands
Engine	1.5L EcoBoost^® Engine with Auto Start-Stop Technology	2.0L EcoBoost^® Engine with Auto Start-Stop Technology
Available Features	Class II Trailer Tow Package w/ Trailer Sway Control	Class II Trailer Tow Package w/ Trailer Sway Control
Max. Trailer Weight	2,000 lbs.	2,200 lbs.

Chassis Specifications

Switch to Imperial Units Switch to Metric Units

Front suspension	Independent MacPherson strut-type with stabilizer bar, twin-tube hydraulic gas-pressurized shocks
Rear suspension	Independent double lateral link semi-trailing arms with stabilizer bar, springs and hydraulic gas-pressurized shocks
Traction assist	AdvanceTrac^® with RSC^® (Roll Stability Control^™ )
Brakes	Four-Wheel Disc Brakes with Anti-Lock Brake System (ABS)
Steering	Electric Power-Assisted Steering (EPAS)

Front suspension	Independent MacPherson strut-type with stabilizer bar, twin-tube hydraulic gas-pressurized shocks
Rear suspension	Independent double lateral link semi-trailing arms with stabilizer bar, springs and hydraulic gas-pressurized shocks
Traction assist	AdvanceTrac^® with RSC^® (Roll Stability Control^™ )
Brakes	Four-Wheel Disc Brakes with Anti-Lock Brake System (ABS)
Steering	Electric Power-Assisted Steering (EPAS)

Fuel Consumption and Engine Highlights

Switch to Imperial Units Switch to Metric Units

	Base/Big Bend/Outer Banks	Badlands
Engine Type	1.5L EcoBoost^® Engine with Auto Start-Stop Technology	2.0L EcoBoost^® Engine with Auto Start-Stop Technology
Fuel Consumption *Fuel consumption ratings based on Government of Canada approved test methods. Actual fuel consumption will vary.	Est. 9.3 L/100km city, 8.3 L/100km highway, 8.9 L/100km combined*	Est. 11.1 L/100km city, 8.9 L/100km highway, 10.1 L/100km combined*

	Base/Big Bend/Outer Banks	Badlands
Engine Type	1.5L EcoBoost^® Engine with Auto Start-Stop Technology	2.0L EcoBoost^® Engine with Auto Start-Stop Technology
Fuel Consumption *Fuel consumption ratings based on Government of Canada approved test methods. Actual fuel consumption will vary.	30 city/ 34 hwy / 32 combined (mpg-lmp)*	25 city/ 32 hwy / 28 combined (mpg-lmp)*

Vehicle Highlights

Switch to Imperial Units Switch to Metric Units

Max Seating Capacity	5
Drive Type	4X4
Transmission	8-Speed Automatic
Wheelbase	2,670 mm
Maximum Towing Capacity	2,200 lbs. (Bronco Sport Badlands model with available Class II Trailer Tow Package w/ Trailer Sway Control)
Wheels Available	17" Sparkle Silver - Standard on Bronco Sport Base model
	17" Carbonized Grey-Painted High Gloss Aluminum - Standard on Bronco Sport Big Bend model
	18" Ebony Black-Painted Machined-Face Aluminum - Standard on Bronco Sport Outer Banks model
	17" Carbonized Grey-Painted Aluminum - Standard on Bronco Sport Badlands model
	18" Ebony Black-Painted Machined-Face Aluminum (64M) - Available on Bronco Sport Big Bend model
	17" Carbonized Grey-Painted Low Gloss Aluminum - Available on Bronco Sport Badlands model
Warranty	Basic: 3 years / 60,000 km Powertrain: 5 years / 100,000 km Safety Restraint System: 5 years / 100,000 km Corrosion (Perforation only): 5 years / Unlimited distance Roadside Assistance Program: 5 years / 100,000 km

Max Seating Capacity	5
Drive Type	4X4
Transmission	8-Speed Automatic
Wheelbase	105.1 in.
Maximum Towing Capacity	2,200 lbs. (Bronco Sport Badlands model with available Class II Trailer Tow Package w/ Trailer Sway Control)
Wheels Available	17" Sparkle Silver - Standard on Bronco Sport Base model
	17" Carbonized Grey-Painted High Gloss Aluminum - Standard on Bronco Sport Big Bend model
	18" Ebony Black-Painted Machined-Face Aluminum - Standard on Bronco Sport Outer Banks model
	17" Carbonized Grey-Painted Aluminum - Standard on Bronco Sport Badlands model
	18" Ebony Black-Painted Machined-Face Aluminum (64M) - Available on Bronco Sport Big Bend model
	17" Carbonized Grey-Painted Low Gloss Aluminum - Available on Bronco Sport Badlands model
Warranty	Basic: 3 years / 36,000 miles Powertrain: 5 years / 60,000 miles Safety Restraint System: 5 years / 60,000 miles Corrosion (Perforation only): 5 years / Unlimited miles Roadside Assistance Program: 5 years / 60,000 miles

2021 Ford® Bronco Sport Big Bend SUV | Model Details & Specs

COMMERCIAL TRUCKS

PERFORMANCE VEHICLES

FUTURE VEHICLES

SUVS & CROSSOVERS

TRUCKS & VANS

ELECTRIFIED

CARS

2021 Bronco Sport Big Bend

Key Features

Cloth (Easy to Clean) Seating Surfaces

Remote Start System

Heated Front Seats

Exterior Features

Appearance

Standard

Optional

Windows & Glass

Standard

Interior Features

Climate

Standard

Comfort and Convenience

Standard

Optional

Entertainment Systems

Standard

Optional

Seating

Standard

Packages

Packages

Standard

Optional

Standard Features

Standard

Power and Handling

Handling

Standard

Optional

Power

Standard

Safety

Safety

Standard

Security

Standard

Specifications

Exterior Dimensions

Interior Dimensions

Capacities: Passengers, Luggage, Fuel

Engine Specifications

Towing

Chassis Specifications

Fuel Consumption and Engine Highlights

Vehicle Highlights
