U.S. computer-generated image shown.
| Drive System | 4x4 |
| mm | |
| Wheelbase | 2,670 |
| Length | 4,386 |
| Height - Excluding Options (2.0L/1.5L) | 1,813 / 1,785 |
| Width - Including Mirrors | 2,087 |
| Width - Excluding Mirrors | 1,888 |
| Width - Mirrors Folded | 1,938 |
| Track - Front | 1,610 |
| Track - Rear | 1,595 |
| Drive System | 4x4 |
| in. | |
| Wheelbase | 105.1 |
| Length | 172.7 |
| Height - Excluding Options (2.0L/1.5L) | 71.4 / 70.3 |
| Width - Including Mirrors | 82.2 |
| Width - Excluding Mirrors | 74.3 |
| Width - Mirrors Folded | 76.3 |
| Track - Front | 63.4 |
| Track - Rear | 62.8 |
| Head Room | mm |
| First Row (without Moonroof) | 1,055 |
| First Row (with Moonroof) | 992 |
| Second Row | 1,059 |
| Leg Room | |
| First Row (maximum) | 1,077 |
| Second Row | 936 |
| Hip Room | |
| First Row | 1,403 |
| Second Row | 1,356 |
| Shoulder Room | |
| First Row | 1,455 |
| Second Row | 1,412 |
| Head Room | in. |
| First Row (without Moonroof) | 41.5 |
| First Row (with Moonroof) | 39.1 |
| Second Row | 41.7 |
| Leg Room | |
| First Row (maximum) | 42.4 |
| Second Row | 36.9 |
| Hip Room | |
| First Row | 55.2 |
| Second Row | 53.4 |
| Shoulder Room | |
| First Row | 57.3 |
| Second Row | 55.6 |
| Maximum Seating Capacity | 5 |
| Standard Seating Capacity | 5 |
| L (unless otherwise noted) | |
| Passenger Volume - Base Roof | 2,992 |
| Passenger Volume - Moonroof | 2,897 |
| Cargo Volume Behind 1st Row (w/o Moonroof) | 1,845 |
| Cargo Volume Behind 1st Row (w/Moonroof) | 1,703 |
| Cargo Volume Behind 2nd Row (w/o Moonroof) | 920 |
| Cargo Volume Behind 2nd Row (w/Moonroof) | 822 |
| Fuel capacity | 61 |
| Base Curb Weight - 1.5L EcoBoost® | 1,568 kg |
| Base Curb Weight - 2.0L EcoBoost® | 1,684 kg |
| Maximum Seating Capacity | 5 |
| Standard Seating Capacity | 5 |
| cu. ft. (unless otherwise noted) | |
| Passenger Volume - Base Roof | 105.7 |
| Passenger Volume - Moonroof | 102.3 |
| Cargo Volume Behind 1st Row (w/o Moonroof) | 65.2 |
| Cargo Volume Behind 1st Row (w/Moonroof) | 60.1 |
| Cargo Volume Behind 2nd Row (w/o Moonroof) | 32.5 |
| Cargo Volume Behind 2nd Row (w/Moonroof) | 29 |
| Fuel capacity | 16 gal. |
| Base Curb Weight - 1.5L EcoBoost® | 3,457 lbs. |
| Base Curb Weight - 2.0L EcoBoost® | 3,713 lbs. |
| Big Bend®/Heritage/Free Wheeling™/Outer Banks® | Badlands® | |
| Engine type | 1.5L EcoBoost® Engine with Auto Start-Stop Technology | 2.0L EcoBoost® Engine with Auto Start-Stop Technology |
| 1.5L Ti-VCT GTDI I-3 | 2.0L Ti-VCT GTDI I-3 | |
| Drive type | 4x4 | Advanced 4x4 with Twin-Clutch Rear Drive Unit |
| Exhaust | Dual Exhaust | Dual Exhaust |
| Transmission type | 8-speed Automatic Transmission | 8-speed Automatic Transmission; SelectShift® with Paddle shifters |
| Horsepower* (SAE net@rpm) | 181 @ 6,000 rpm | 250 @ 5,500 rpm |
| Torque* (lb.-ft.@rpm) | 190 @ 3,000 rpm | 277 @ 3,000 rpm |
| Compression ratio | 11.0:1 | 10.0:1 |
| Valve lifters | Direct Injection and Port Fuel Injection | Direct acting mechanical bucket |
| Engine block material | Aluminum | Aluminum |
| Cylinder head material | Aluminum | Aluminum |
| Induction system | Single Turbocharged | Single Twin-Scroll Turbocharged |
| Fuel delivery | Direct injection | Direct injection |
| Fuel (minimum) | Regular unleaded | Regular unleaded |
| *Horsepower and torque ratings based on premium fuel per SAE J1349 standard. Your results may vary. |
| Big Bend®/Heritage/Free Wheeling™/Outer Banks® | Badlands® | |
| Engine type | 1.5L EcoBoost® Engine with Auto Start-Stop Technology | 2.0L EcoBoost® Engine with Auto Start-Stop Technology |
| 1.5L Ti-VCT GTDI I-3 | 2.0L Ti-VCT GTDI I-3 | |
| Drive type | 4x4 | Advanced 4x4 with Twin-Clutch Rear Drive Unit |
| Exhaust | Dual Exhaust | Dual Exhaust |
| Transmission type | 8-speed Automatic Transmission | 8-speed Automatic Transmission; SelectShift® with Paddle shifters |
| Horsepower* (SAE net@rpm) | 181 @ 6,000 rpm | 250 @ 5,500 rpm |
| Torque* (lb.-ft.@rpm) | 190 @ 3,000 rpm | 277 @ 3,000 rpm |
| Compression ratio | 11.0:1 | 10.0:1 |
| Valve lifters | Direct Injection and Port Fuel Injection | Direct acting mechanical bucket |
| Engine block material | Aluminum | Aluminum |
| Cylinder head material | Aluminum | Aluminum |
| Induction system | Single Turbocharged | Single Twin-Scroll Turbocharged |
| Fuel delivery | Direct injection | Direct injection |
| Fuel (minimum) | Regular unleaded | Regular unleaded |
| *Horsepower and torque ratings based on premium fuel per SAE J1349 standard. Your results may vary. |
| Model | Big Bend®/Heritage/Free Wheeling™/Outer Banks® | Badlands® |
| Engine | 1.5L EcoBoost® Engine with Auto Start-Stop Technology | 2.0L EcoBoost® Engine with Auto Start-Stop Technology |
| Available Features | Class II Trailer Tow Package w/ Trailer Sway Control | Class II Trailer Tow Package w/ Trailer Sway Control |
| Max. Trailer Weight | 907 kg | 997 kg |
| Model | Big Bend®/Heritage/Free Wheeling™/Outer Banks® | Badlands® |
| Engine | 1.5L EcoBoost® Engine with Auto Start-Stop Technology | 2.0L EcoBoost® Engine with Auto Start-Stop Technology |
| Available Features | Class II Trailer Tow Package w/ Trailer Sway Control | Class II Trailer Tow Package w/ Trailer Sway Control |
| Max. Trailer Weight | 2,000 lbs. | 2,200 lbs. |
| Front suspension | Independent MacPherson strut-type with stabilizer bar, twin-tube hydraulic gas-pressurized shocks |
| Rear suspension | Independent double lateral link semi-trailing arms with stabilizer bar, springs and hydraulic gas-pressurized shocks |
| Traction assist | AdvanceTrac® with RSC® (Roll Stability Control™) |
| Brakes | Four-Wheel Disc Brakes with Anti-Lock Brake System (ABS) |
| Steering | Electric Power-Assisted Steering (EPAS) |
| Front suspension | Independent MacPherson strut-type with stabilizer bar, twin-tube hydraulic gas-pressurized shocks |
| Rear suspension | Independent double lateral link semi-trailing arms with stabilizer bar, springs and hydraulic gas-pressurized shocks |
| Traction assist | AdvanceTrac® with RSC® (Roll Stability Control™) |
| Brakes | Four-Wheel Disc Brakes with Anti-Lock Brake System (ABS) |
| Steering | Electric Power-Assisted Steering (EPAS) |
| Engine Highlights | ||
| Big Bend®/Heritage/Free Wheeling™/Outer Banks® | Badlands® | |
| Engine Type | 1.5L EcoBoost® Engine with Auto Start-Stop Technology | 2.0L EcoBoost® Engine with Auto Start-Stop Technology |
| Vehicle Highlights | ||
| Max Seating Capacity | 5 | |
| Drive Type | 4x4 | |
| Transmission | 8-Speed Automatic | |
| Wheelbase | 2,670 mm | |
| Maximum Towing Capacity | 2,200 lbs. (Bronco® Sport Badlands® model with available Class II Trailer Tow Package w/ Trailer Sway Control) |
|
| Wheels Available | 17" Carbonized Grey-Painted High Gloss Aluminum - Standard on Bronco® Sport Big Bend® model | |
| 17" Oxford White Painted Aluminum - Standard on Heritage | ||
| 17" Ebony Race Red Painted - Standard on Free Wheeling™ | ||
| 18" Ebony Black-Painted Machined-Face Aluminum - Standard on Bronco® Sport Outer Banks® model | ||
| 17" Carbonized Grey-Painted Aluminum - Standard on Bronco® Sport Badlands® model | ||
| 18" Ebony Black-Painted Machined-Face Aluminum (64M) - Available on Bronco® Sport Big Bend® model | ||
| 17" Matte Black Painted - Optional on Big Bend® as part of Black Appearance Package | ||
| 17" Carbonized Grey-Painted Low Gloss Aluminum - Available on Bronco® Sport Badlands® model | ||
| Warranty | Basic: 3 years / 60,000 km | |
| Powertrain: 5 years / 100,000 km | ||
| Safety Restraint System: 5 years / 100,000 km | ||
| Corrosion (Perforation only): 5 years / Unlimited distance | ||
| Roadside Assistance Program: 5 years / 100,000 km |
| Engine Highlights | ||
| Big Bend®/Heritage/Free Wheeling™/Outer Banks® | Badlands® | |
| Engine Type | 1.5L EcoBoost® Engine with Auto Start-Stop Technology | 2.0L EcoBoost® Engine with Auto Start-Stop Technology |
| Vehicle Highlights | ||
| Max Seating Capacity | 5 | |
| Drive Type | 4x4 | |
| Transmission | 8-Speed Automatic | |
| Wheelbase | 105.1 in. | |
| Maximum Towing Capacity | 2,200 lbs. (Bronco® Sport Badlands® model with available Class II Trailer Tow Package w/ Trailer Sway Control) |
|
| Wheels Available | 17" Carbonized Grey-Painted High Gloss Aluminum - Standard on Bronco® Sport Big Bend® model | |
| 17" Oxford White Painted Aluminum - Standard on Heritage | ||
| 17" Ebony Race Red Painted - Standard on Free Wheeling™ | ||
| 18" Ebony Black-Painted Machined-Face Aluminum - Standard on Bronco® Sport Outer Banks® model | ||
| 17" Carbonized Grey-Painted Aluminum - Standard on Bronco® Sport Badlands® model | ||
| 18" Ebony Black-Painted Machined-Face Aluminum (64M) - Available on Bronco® Sport Big Bend® model | ||
| 17" Matte Black Painted - Optional on Big Bend® as part of Black Appearance Package | ||
| 17" Carbonized Grey-Painted Low Gloss Aluminum - Available on Bronco® Sport Badlands® model | ||
| Warranty | Basic: 3 years / 36,000 miles | |
| Powertrain: 5 years / 60,000 miles | ||
| Safety Restraint System: 5 years / 60,000 miles | ||
| Corrosion (Perforation only): 5 years / Unlimited miles | ||
| Roadside Assistance Program: 5 years / 60,000 miles |
