Wheels & Tires
Standard
- Underbody-mounted full-size spare tire
- P275/55R20 all-season BSW tire
Optional
- 22" Polished Aluminum Wheels
- P285/45R22 all-season BSW tire
U.S. Model Shown.
Key Features
Panoramic Vista Roof®
(Power Open/Close with Power Shade)
The available Panoramic Vista Roof® features two panels over the first and second rows. The front panel opens for an open air driving experience.
...less
Heated second-row outboard seats
Heated first- and second-row seats are standard on Limited and Platinum.
...less
U.S. Model Shown.
Connectivity Package
Remain connected to your Expedition and the world around you.
•FordPassTM Connect
•Two smart charging USB ports in the 3rd row
•Wireless charging pad
Power and Handling
Handling
Standard
- Drive Train-4x4
- Fully boxed frame
- Suspension-Multilink Independent Rear
- Electronic Power-Assisted Steering (EPAS)
- Front and rear stabilizer bars
- Non-limited slip 3.31 rear axle
- Trailer Sway Control
- Front Tow Hooks
Optional
- Heavy-Duty Engine Radiator (Only Available as part of the Heavy Duty Trailer Tow Package)
- Pro Trailer Back up Assist (Only Available as part of the Heavy Duty Trailer Tow Package)
- Integrated Trailer Brake Control (Only Available as part of the Heavy Duty Trailer Tow Package)
- Two Speed Transfer Case (Only Available as part of the Heavy Duty Trailer Tow Package)
- Limited slip 3.73 rear axle (Only Available as a part of the FX4 Off-Road Package)
Power
Standard
- 3.5L EcoBoost®
engine
- Transmission-10-Speed Automatic with Selectshift® capability
- Engine Block Heater
- Hill Start Assist™
Hill Descent Control™
- Fuel Tank: 113.5 litres (30 gallons)
Interior Features
Climate
Standard
- Tri-zone Electronic Automatic Temperature Control (TEATC)
- Rear auxiliary climate control
Comfort and Convenience
Standard
- Overhead console with sunglass holder and conversation mirror
- Large front floor console
- Cupholders-(2) 1st Row+(2) Bottle holders in front-doors (3) 3rd Row
- Door-Locks-Power w/Autolock
- Power windows with one-touch-up/down for driver's window
- Rear Window Defroster
- Power rear quarter windows
- Carpeted floor
- Carpeted first- and second-row floor mats
- Cargo Management System
- Cargo Protector
- Lighting-Illuminated Entry w/Approach Lamps
- Delayed Accessory Lighting
- Dome Lamp-1st Row and Cargo
- Reading Lamps-1st Row
- Power-Adjustable Pedals
Analogue RPM and Speed Gauges with digital minor gauges and 8" Center Display
- Rearview Mirror-Electrochromatic w/display screen
- Reverse Sensing System
- Front Park Assist
- Powerpoints-(3) 1st Row, (1) 2nd Row Centre Console, (1) Cargo Area
- AC Outlet: 110V
- Shifter-Rotary Gear Shift Dial, Centre Console Mounted
- Woodgrain appliqués
- Leather-wrapped power tilt/telescoping steering wheel with audio controls and Memory
- Heated Steering Wheel
- Cruise control
- Universal garage door opener
- Sunvisors w/Dual Illuminated Mirrors
- Passenger assist handles
- Coat Hooks-(2) 2nd Row, (2) 3rd Row
- Grab Handles-(2) 1st Row, (2) 2nd Row and Liftgate
- Wipers-Intermittent Front and Rear
- Windshield Wiper De-Icer
- Liftgate with flip-up glass
- Hands-Free Foot-Activated Power Liftgate
- MyKey®
- Push-Button Start
- PEPS (Passive Entry/Passive Start)
- Ambient Lighting
Optional
- All-Weather Floor Mats (RPO)
- Advanced Cargo Management System
- Cargo Mat-Reversible
- Adaptive Cruise Control w/stop and go
- Lane Keeping Aid
- Enhanced Active Park Assist with Auto Park
- Rain-sensing front wipers
Entertainment Systems
Standard
- Voice-Activated Navigation System
- SYNC®
3
- FordPass Connect™
4G WiFi Modem
- Connectivity Package
- Smart-Charging Multimedia USB Ports in Media Hub-Two (2)
- Smart-Charging Multimedia USB Ports, Second Row-Two (2)
- Smart-Charging USB Ports, Third Row-Two (2)
- Wireless Charging in Media Hub
- Audio-B&O™
Sound System by Bang & Olufsen, 12-Speakers
Seating
Standard
- Front perforated leather-trimmed
- 10-way Power Driver's and Passenger Seats with Power Recline, 2-way Power Lumbar, and Driver Memory feature
- Heated and Ventilated Front Seats
- 2nd-row 40/20/40 bench
- 2nd Row 40/20/40 PowerFold® Tip-and-Slide seats
- 3rd Row 60/40 PowerFold® Seat
- Heated second-row outboard seats
PowerFold® 3rd-row Seat
Optional
- 2nd Row Tip-and-Slide Bucket Seats
Exterior Features
Appearance
Standard
- Bumpers-Body-Colour
- Exhaust-Single, Hidden
- Door Handles-Body-Colour with Chrome Insert
- Fog Lamps-Halogen
- Headlamps-Halogen Projector Lamps
- Taillamps-LED
- Daytime Running Lamps
- Roof Rack-Bright Stainless Side Rails
- Black luggage rack crossbars
- Running Boards, Power Deployable-Magnetic Painted with Polished Stainless Accent
- Easy Fuel®
Capless Fuel Filler
- Bright Chrome Grille with Silver Lining Painted Accents
- Body-Colour Mirror Caps
- Mirrors, Sideview-Power-Folding with Autofold, Memory, Power and Heated Glass, Turn Signal Indicators, Security Approach Lamps, Driver's side Auto-Dimming
- BLIS®
(Blind Spot Information System) with cross-traffic alert with Trailer Tow Monitoring
- Integrated Class IV Trailer hitch receiver
- Wiring Harness w/4&7 pin connector
Optional
- Fog Lamps-LED
- Headlamps-LED
- Auto Highbeam Headlamp
- White Platinum Metallic Tri-Coat
- Ruby Red Tinted Clear Metallic
Windows & Glass
Standard
- Glass-Solar-Tinted Front/Privacy Tinted Rear
- Panoramic Vista Roof® (Power Open/Close with Power Shade)
Safety
Safety
Standard
- AdvanceTrac®
with Roll Stability Control™
(RSC®
)
- Dual-stage front airbags
- Three-point safety belts at all seating positions
- Seat belt pre-tensioners, Load Limiting retractors, dual-stage front airbags, driver seat position sensing & crash severity sensing
- Safety Canopy® System
- Side-Impact Airbags
- Child Safety Locks-Rear
- LATCH (Lower Anchors & Tethers for Children)
- Brakes-4-Wheel Disc (ABS)
- Tire-Pressure Monitoring System (TPMS)
- SOS Post-Crash Alert System™
- Traction Control (Brake Assist & Engine Braking)
Security
Standard
- Security-SecuriLock® Passive Anti-Theft System (PATS)
- Remote keyless entry system
- Perimeter Anti-theft Alarm
- SecuriCode™
keyless entry keypad
- Rear View Camera
Optional
- 360-degree Camera with Split View
- Second-Row Outboard Seating Inflatable Safety Belts
Packages
Free Standing Packages
Standard
- Advanced Security Package
Optional
- Stealth Edition Package
- Heavy-Duty Trailer Tow Package
- Driver Assistance Package
- Cargo Package
Standard Features
Standard
- Equipment Group 300A
Optional
- Equipment Group 302A
- Equipment Group 303A
Accessories
Exterior
Standard
- Remote Start System
Interior
Optional
- Dual Headrest Rear Seat Entertainment System
Specifications
| Exterior Dimensions |
||
|---|---|---|
| Expedition 4x4 [mm] |
Expedition MAX 4x4 [mm] |
|
| Wheelbase |
3112 |
3342 |
| Length |
5333 |
5635 |
| Height | 1941 |
1936 |
| Width - without Mirrors | 2030 |
2030 |
| Width - with Mirrors | 2373 |
2373 |
| Width - with Mirrors Folded | 2124 |
2124 |
| Front Track | 1716 |
1716 |
| Rear Track | 1708 | 1708 |
| Front Overhang | 971 | 971 |
| Rear Overhang | 1251 | 1322 |
| Approach Angle (degrees) | 23,3 | 23,7 |
| Departure Angle (degrees) | 21,9 | 21,3 |
| Ramp Breakover Angle (degrees) | 21,4 | 20,1 |
| Minimum Running Ground Clearance |
248 | 246 |
Exterior Dimensions |
||
|---|---|---|
Expedition 4x4 [in.] |
Expedition MAX 4x4 [in.] |
|
| Wheelbase |
122.5 | 131.6 |
| Length |
210.0 |
221.9 |
| Height |
76.4 |
76.2 |
| Width - without Mirrors | 79.9 | 79.9 |
| Width - with Mirrors |
93.4 |
93.4 |
| Width - with Mirrors Folded |
83.6 |
83.6 |
| Front Track |
67.6 |
67.6 |
| Rear Track |
67.2 | 67.2 |
| Front Overhang |
38.2 | 38.2 |
| Rear Overhang | 49.3 | 52.0 |
| Approach Angle (degrees) |
23.3 | 23.7 |
| Departure Angle (degrees) |
21.9 | 21.3 |
| Ramp Breakover Angle (degrees) |
21.4 | 20.1 |
| Minimum Running Ground Clearance |
9.8 | 9.7 |
| Interior Dimensions |
||
|---|---|---|
| Expedition 4x4 [mm] |
Expedition MAX 4x4 [mm] |
|
| Head Room - 1st Row |
1068 |
1068 |
| Head Room - 2nd Row |
1015 |
1015 |
| Head Room - 3rd Row |
948 | 950 |
| Leg Room - 1st Row (Max.) |
1115 | 1115 |
| Leg Room - 2nd Row |
1053 | 1053 |
| Leg Room - Second Row (Seat Full Rearward) [mm] |
1081 | 1081 |
| Leg Room - 3rd Row |
917 | 917 |
| Leg Room - Third Row (Second Row Seat Full Forward) [mm] | 1038 | 1038 |
| Hip Room - 1st Row | 1580 | 1580 |
| Hip Room - 2nd Row |
1591 | 1591 |
| Hip Room - 3rd Row |
1305 | 1305 |
| Shoulder Room - 1st Row |
1648 | 1648 |
| Shoulder Room - 2nd Row |
1647 | 1647 |
| Shoulder Room - 3rd Row |
1630 | 1630 |
| Interior Dimensions |
||
|---|---|---|
| Expedition 4x4 [in.] |
Expedition MAX 4x4 [in.] |
|
| Head Room - 1st Row | 42.0 |
42.0 |
| Head Room - 2nd Row |
40.0 | 40.0 |
| Head Room - 3rd Row |
37.3 | 37.4 |
| Leg Room - 1st Row (Max.) |
43.9 | 43.9 |
| Leg Room - 2nd Row |
41.5 | 41.5 |
| Leg Room - Second Row (Seat Full Rearward) [mm] |
42.6 |
42.6 |
| Leg Room - 3rd Row |
36.1 | 36.1 |
| Leg Room - Third Row (Second Row Seat Full Forward) [mm] | 40.9 | 40.9 |
| Hip Room - 1st Row | 62.2 | 62.2 |
| Hip Room - 2nd Row |
62.6 | 62.6 |
| Hip Room - 3rd Row | 51.4 | 51.4 |
| Shoulder Room - 1st Row |
64.9 | 64.9 |
| Shoulder Room - 2nd Row | 64.8 | 64.8 |
| Shoulder Room - 3rd Row | 64.2 | 64.3 |
| Capacities: Interior Volume |
||
|---|---|---|
| Expedition 4x4 (L) | Expedition MAX 4x4 [L] |
|
| Passenger Volume |
4867.9 |
4871.7 |
| Cargo Volume Behind 1st Row | 2961.7 | 3439.2 |
| Cargo Volume Behind 2nd Row |
1627.0 | 2076.8 |
| Cargo Volume Behind Second Row - Second Row Seat Full Forward |
1800.0 | 2253.8 |
| Cargo Volume Behind 3rd Row |
546.4 | 972.2 |
| Cargo Volume Behind Third Row - Third Row Seat Full Upright | 592.8 |
1018.9 |
| Capacities: Fuel
|
||
| Expedition 4x4 [L] |
Expedition MAX 4x4 [L] |
|
| Fuel Capacity |
94.6 litres |
113.5 litres |
| Capacities: Weight | ||
| Expedition 4x4 [kg.] |
Expedition MAX 4x4 [kg.] |
|
| Estimated Base Curb Weight | 2550.6 |
2628.1 |
| Seating:
|
||
| Maximum Seating Capacity |
8 |
8 |
| Capacities: Interior Volume |
||
|---|---|---|
| Expedition 4x4 [cu.ft.] |
Expedition MAX 4x4 [cu.ft.] |
|
| Passenger Volume | 171.9 | 172.0 |
| Cargo Volume Behind 1st Row | 104.6 | 121.5 |
| Cargo Volume Behind 2nd Row |
57.5 | 73.3 |
| Cargo Volume Behind Second Row - Second Row Seat Full Forward |
63.6 | 79.6 |
| Cargo Volume Behind 3rd Row |
19.3 | 34.3 |
| Cargo Volume Behind Third Row - Third Row Seat Full Upright |
20.9 | 36.0 |
| Capacities: Fuel
|
||
| Expedition 4x4 [gallons] |
Expedition MAX 4x4 [gallons] |
|
| Fuel Capacity |
25 gallons | 30 gallons |
| Capacities: Weight
|
||
| Expedition 4x4 [lbs.] |
Expedition MAX 4x4 [lbs.] |
|
| Estimated Base Curb Weight |
5623 | 5794 |
| Seating:
|
||
| Maximum Seating Capacity |
8 | 8 |
Engine Specifications |
||||
|---|---|---|---|---|
| Expedition 4x4 (XLT, Limited) |
Expedition 4x4 (Platinum) |
Expedition MAX 4x4 (Limited) |
Expedition MAX 4x4 (Platinum) |
|
| Drive type |
Control Trac® 4-wheel drive | Control Trac® 4-wheel drive |
Control Trac® 4-wheel drive | Control Trac® 4-wheel drive |
| Engine type |
3.5L EcoBoost® V6 | 3.5L EcoBoost®
V6 |
3.5L EcoBoost® V6 | 3.5L EcoBoost® V6 |
| Transmission |
10-speed automatic with SelectShift®
|
10-speed automatic with SelectShift®
|
10-speed automatic with SelectShift® | 10-speed automatic with SelectShift®
|
| Final drive ratio |
3.31 (non-limited slip standard); 3.73 (limited slip optional) | 3.31 (non-limited slip standard); 3.73 (limited slip optional) |
3.73 (limited slip available) |
3.73 (limited slip available) |
Fuel consumption *Fuel consumption ratings based on Transport Canada approved test methods. Actual fuel consumption will vary. |
14.1 L/100km city, 10.6 L/100km hwy, 12.5 L/100km combined* |
14.1 L/100km city, 10.6 L/100km hwy, 12.5 L/100km combined* |
14.7 L/100km city, 11.2 L/100km hwy, 13.1 L/100km combined* |
14.7 L/100km city, 11.2 L/100km hwy, 13.1 L/100km combined* |
| Horsepower (SAE net @rpm) |
375 @ 5,000 |
400 @ 5,000 |
375 @ 5,000 |
400 @ 5,000 |
| Torque (lb.-ft. @rpm) |
470 @ 2,250 |
480 @ 2,250 |
470 @ 2,250 |
480 @ 2,250 |
| Compression ratio | 10.0:1 |
10.0:1 |
10.0:1 |
10.0:1 |
Valvetrain |
Twin independent Variable Camshaft Timing (Ti-VCT) |
Twin independent Variable Camshaft Timing (Ti-VCT) |
Twin independent Variable Camshaft Timing (Ti-VCT) |
Twin independent Variable Camshaft Timing (Ti-VCT) |
| Fuel delivery | Gasoline Direct-injection |
Gasoline Direct-injection |
Gasoline Direct-injection |
Gasoline Direct-injection |
| Technology |
Twin Turbochargers |
Twin Turbochargers |
Twin Turbochargers |
Twin Turbochargers |
| Exhaust | Single, stainless steel |
Single, stainless steel |
Single, stainless steel |
Single, stainless steel |
| Engine block type |
Die-cast aluminum |
Die-cast aluminum |
Die-cast aluminum |
Die-cast aluminum |
| Cylinder head material |
Aluminum alloy |
Aluminum alloy |
Aluminum alloy |
Aluminum alloy |
| Engine Specifications |
||||
|---|---|---|---|---|
| Expedition 4x4 (XLT, Limited) | Expedition 4x4 (Platinum) |
Expedition MAX 4x4 (Limited) |
Expedition MAX 4x4 (Platinum) |
|
| Drive type |
Control Trac® 4-wheel drive | Control Trac®
4-wheel drive |
Control Trac® 4-wheel drive | Control Trac®
4-wheel drive |
| Engine type |
3.5L EcoBoost®
V6 |
3.5L EcoBoost®
V6 |
3.5L EcoBoost®
V6 |
3.5L EcoBoost®
V6 |
| Transmission |
10-speed automatic with SelectShift®
|
10-speed automatic with SelectShift® | 10-speed automatic with SelectShift® | 10-speed automatic with SelectShift® |
| Final drive ratio |
3.31 (non-limited slip standard); 3.73 (limited slip optional) |
3.31 (non-limited slip standard); 3.73 (limited slip optional) |
3.73 (limited slip available) |
3.73 (limited slip available) |
Fuel consumption *Fuel consumption ratings based on Transport Canada approved test methods. Actual fuel consumption will vary. |
20 mpg-lmp city/ 27 mpg-lmp hwy/ 23 mpg-lmp combined* |
20 mpg-lmp city/ 27 mpg-lmp hwy/ 23 mpg-lmp combined* |
19 mpg-lmp city/ 25 mpg-lmp hwy/ 22 mpg-lmp combined* |
19 mpg-lmp city/ 25 mpg-lmp hwy/ 22 mpg-lmp combined* |
| Horsepower (SAE net @rpm) |
375 @ 5,000 |
400 @ 5,000 |
375 @ 5,000 |
400 @ 5,000 |
| Torque (lb.-ft. @rpm) |
470 @ 2,250 |
480 @ 2,250 |
470 @ 2,250 |
480 @ 2,250 |
| Compression ratio |
10.0:1 |
10.0:1 |
10.0:1 |
10.0:1 |
Valvetrain |
Twin independent Variable Camshaft Timing (Ti-VCT) |
Twin independent Variable Camshaft Timing (Ti-VCT) |
Twin independent Variable Camshaft Timing (Ti-VCT) |
Twin independent Variable Camshaft Timing (Ti-VCT) |
| Fuel delivery |
Gasoline Direct-injection |
Gasoline Direct-injection |
Gasoline Direct-injection |
Gasoline Direct-injection |
| Technology |
Twin Turbochargers |
Twin Turbochargers | Twin Turbochargers | Twin Turbochargers |
| Exhaust | Single, stainless steel |
Single, stainless steel |
Single, stainless steel |
Single, stainless steel |
| Engine block type |
Die-cast aluminum | Die-cast aluminum | Die-cast aluminum | Die-cast aluminum |
| Cylinder head material | Aluminum alloy |
Aluminum alloy |
Aluminum alloy | Aluminum alloy |
| Front suspension | Independent Short- and Long-Arm (SLA) coil-over-shocks with stabilizer bar |
| Front shocks | Gas charged |
| Rear suspension | Independent multi-link with stabilizer bar (mechanical load-levelling rear suspension available) |
| Rear shocks | Gas charged |
| Brakes |
Power 4-wheel disc Anti-Lock Brake System with brake assist and Electronic Brake Force Distribution |
| Steering |
Electronic Power-Assist (EPAS) rack-and-pinion steering |
| Front suspension |
Independent Short-and Long-Arm (SLA) coil-over-shocks with stabilizer bar |
| Front shocks |
Gas charged |
| Rear suspension |
Independent multi-link with stabilizer bar (mechanical load-levelling rear suspension available) |
| Rear shocks |
Gas charged |
| Brakes |
Power 4-wheel disc Anti-Lock Brake System with brake assist and Electronic Brake Force Distribution |
| Steering |
Electronic Power-Assist (EPAS) rack-and-pinion steering |
Maximum Towing Capabilities – Heavy-Duty Trailer Towing Package
Switch to Imperial Units Switch to Metric Units| Maximum Loaded Trailer Weight |
||||
|---|---|---|---|---|
| Axle Ratio |
Axle Ratio |
GCWR (kg) | 4x4 (kg) | |
| Model | Non-limited Slip |
Limited Slip |
||
| Non-MAX |
3.31 | 3.73 |
6804 |
4173 |
| MAX | - |
3.73 |
6804 |
4127 |
Maximum Loaded Trailer Weight |
||||
|---|---|---|---|---|
| Axle Ratio |
Axle Ratio |
GCWR (lbs.) |
4x4 (lbs.) |
|
| Model | Non-limited Slip | Limited Slip | ||
| Non-MAX |
3.31 | 3.73 | 15200 |
9200 |
| MAX |
- | 3.73 | 15300 | 9100 |
Fuel Consumption |
||
|---|---|---|
| Expedition 4x4 |
Expedition MAX 4x4 |
|
| Engine Type |
3.5L EcoBoost® V6 with TI-VCT | 3.5L EcoBoost®
V6 with Ti-VCT |
Fuel consumption
*Fuel consumption ratings based on Transport Canada approved test methods. Actual fuel consumption will vary. |
14.1 L/100 km city, 11.2 L/100 km hwy, 13.1 L/100 km combined* |
14.7 L/100 km city, 11.4 L/100 km hwy, 13.4 L/100 km combined* |
| Vehicle highlights |
||
| Max Seating Capacity |
8 | |
| Drive (System, Type of Train) |
Control Trac®
4-wheel drive |
|
| Transmissions |
6-speed automatic with SelectShift®
|
|
| Wheelbase |
Expedition 4x4 - 3,022 mm. | |
| Expedition MAX 4x4 - 3,327 mm. |
||
| Maximum Towing Capacity |
Non-MAX 4x4 - 4,173 kg. |
|
| MAX 4x4 - 4,127 kg. |
||
Wheels Available |
18-inch bright machined-aluminum 20-inch machined aluminum with Magnetic painted windows 20-inch polished aluminum (Limited) 20-inch magnetic painted wheel (Limited) 20-inch polished aluminum (Platinum) 22-inch polished aluminum (Platinum) |
|
Warranty |
Basic: 3 years/60,000 km
Corrosion (Perforation Only): 5 years/unlimited km
Powertrain: 5 years/100,000 km
Safety Restraint System: 5 years/100,000 km
Roadside Assistance Program: 5 years/100,000 km |
Fuel Consumption |
||
|---|---|---|
| Expedition 4x4 |
Expedition MAX 4x4 |
|
| Engine Type |
3.5L EcoBoost®
V6 with Ti-VCT |
3.5L EcoBoost®
V6 with Ti-VCT |
Fuel consumption
*Fuel consumption ratings based on Transport Canada approved test methods. Actual fuel consumption will vary. |
20 mpg-lmp city/ 27 mpg-lmp hwy/ 23 mpg-lmp combined* |
19 mpg-lmp city/ 25 mpg-lmp hwy/ 22 mpg-lmp combined* |
| Vehicle highlights | ||
| Max Seating Capacity | 8 | |
| Drive (System, Type of Train) | Control Trac®
4-wheel drive |
|
| Transmissions |
6-speed automatic with SelectShift®
|
|
| Wheelbase |
Expedition 4x4 - 119.0 in. |
|
| Expedition MAX 4x4 - 131.0 in. |
||
| Maximum Towing Capacity |
Non-MAX 4x4 - 9,200 lbs. |
|
| MAX 4x4 - 9,100 lbs. |
||
| Wheels Available |
18-inch bright machined-aluminum 20-inch machined aluminum with Magnetic painted windows 20-inch polished aluminum (Limited) 20-inch magnetic painted wheel (Limited) 20-inch polished aluminum (Platinum) 22-inch polished aluminum (Platinum) |
|
| Warranty |
Basic: 3 years/36,000 miles
Corrosion (Perforation Only): 5 years/unlimited miles
Powertrain: 5 years/60,000 miles
Safety Restraint System: 5 years/60,000 miles
Roadside Assistance Program: 5 years/60,000 miles |
