Power
Standard
3.5L EcoBoost® engine
- Transmission-10-Speed Automatic with Selectshift® capability
- Engine Block Heater
- Hill Start Assist™
- Hill Descent Control™
- Fuel Tank: 94.6 litres (25 gallons)
Language
The available 360-degree camera with split-view display10 uses four cameras – one in the grille, tailgate, and under each of the sideview mirrors. The system enables you to see all sides of the vehicle by stitching the images together and displaying them on a centre-stack screen. It’s useful when manoeuvring in tight spaces or on trails. The camera system includes its own washer to maximize visibility.
...less
Power-deployable running boards are standard on Expedition Limited®, Limited MAX, Platinum and Platinum MAX. Each has a unique colour: Magnetic-painted with polished stainless steel accent on Limited and Limited MAX and polished stainless steel on Platinum and Platinum MAX.
...less
Enjoy the natural light and a breath of fresh air. And you always have the option of sliding the shade forward to keep bright light out of your eyes.
...less
3.5L EcoBoost® engine
Audio-B&O PLAY™ Premium Audio System by HARMAN, 12-Speakers
Analog RPM and Speed Gauges with digital minor gauges and 8" Center Display (Included as part of 202A)
Leather-wrapped power tilt/telescoping steering wheel with audio controls and Memory (Included as part of 202A)
Bumpers-Body-Colour
Expedition 4x4 [mm] | Expedition MAX 4x4 [mm] | |
---|---|---|
Wheelbase | 3112 | 3342 |
Length | 5333 | 5635 |
Height | 1941 | 1936 |
Width - without Mirrors | 2030 | 2030 |
Width - with Mirrors | 2373 | 2373 |
Width - with Mirrors Folded | 2124 | 2124 |
Front Track | 1716 | 1716 |
Rear Track | 1708 | 1708 |
Front Overhang | 971 | 971 |
Rear Overhang | 1251 | 1322 |
Approach Angle (degrees) | 23.3 | 23.7 |
Departure Angle (degrees) | 21.9 | 21.3 |
Ramp Breakover Angle (degrees) | 21.4 | 20.1 |
Minimum Running Ground Clearance | 248 | 246 |
Expedition 4x4 [mm] | Expedition MAX 4x4 [mm] | |
---|---|---|
Wheelbase | 3112 | 3342 |
Length | 5333 | 5635 |
Height | 1941 | 1936 |
Width - without Mirrors | 2030 | 2030 |
Width - with Mirrors | 2373 | 2373 |
Width - with Mirrors Folded | 2124 | 2124 |
Front Track | 1716 | 1716 |
Rear Track | 1708 | 1708 |
Front Overhang | 971 | 971 |
Rear Overhang | 1251 | 1322 |
Approach Angle (degrees) | 23.3 | 23.7 |
Departure Angle (degrees) | 21.9 | 21.3 |
Ramp Breakover Angle (degrees) | 21.4 | 20.1 |
Minimum Running Ground Clearance | 248 | 246 |
Expedition 4x4 [mm] | Expedition MAX 4x4 [mm] | |
---|---|---|
Head Room - 1st Row | 1068 | 1068 |
Head Room - 2nd Row |
1015 | 1015 |
Head Room - 3rd Row | 948 | 948 |
Leg Room - 1st Row (Max.) | 1115 | 1115 |
Leg Room - 2nd Row | 1053 | 1053 |
Leg Room - Second Row (Seat Full Rearward) [mm] | 1081 | 1081 |
Leg Room - 3rd Row | 917 | 917 |
Leg Room - Third Row (Second Row Seat Full Forward) [mm] |
1038 | 1038 |
Hip Room - 1st Row | 1580 | 1580 |
Hip Room - 2nd Row | 1591 | 1591 |
Hip Room - 3rd Row | 1305 | 1305 |
Shoulder Room - 1st Row | 1648 | 1648 |
Shoulder Room - 2nd Row | 1647 | 1647 |
Shoulder Room - 3rd Row |
1630 | 1630 |
Expedition 4x4 [mm] | Expedition MAX 4x4 [mm] | |
---|---|---|
Head Room - 1st Row | 1068 | 1068 |
Head Room - 2nd Row |
1015 | 1015 |
Head Room - 3rd Row | 948 | 948 |
Leg Room - 1st Row (Max.) | 1115 | 1115 |
Leg Room - 2nd Row | 1053 | 1053 |
Leg Room - Second Row (Seat Full Rearward) [mm] | 1081 | 1081 |
Leg Room - 3rd Row | 917 | 917 |
Leg Room - Third Row (Second Row Seat Full Forward) [mm] |
1038 | 1038 |
Hip Room - 1st Row | 1580 | 1580 |
Hip Room - 2nd Row | 1591 | 1591 |
Hip Room - 3rd Row | 1305 | 1305 |
Shoulder Room - 1st Row | 1648 | 1648 |
Shoulder Room - 2nd Row | 1647 | 1647 |
Shoulder Room - 3rd Row |
1630 | 1630 |
Expedition 4x4 [L] | Expedition MAX 4x4 [L] | |
---|---|---|
Passenger Volume | 4868 | 4872 |
Cargo Volume Behind 1st Row |
2962 | 3439 |
Cargo Volume Behind 2nd Row | 1627 |
2077 |
Cargo Volume Behind Second Row - Second Row Seat Full Forward | 1800 | 2254 |
Cargo Volume Behind 3rd Row | 546 | 973 |
Cargo Volume Behind Third Row - Third Row Seat Full Upright | 593 |
1019 |
Expedition 4x4 [L] | Expedition MAX 4x4 [L] | |
---|---|---|
Passenger Volume | 4868 | 4872 |
Cargo Volume Behind 1st Row |
2962 | 3439 |
Cargo Volume Behind 2nd Row | 1627 |
2077 |
Cargo Volume Behind Second Row - Second Row Seat Full Forward | 1800 | 2254 |
Cargo Volume Behind 3rd Row | 546 | 973 |
Cargo Volume Behind Third Row - Third Row Seat Full Upright | 593 |
1019 |
Expedition 4x4 [L] | Expedition MAX 4x4 [L] | |
---|---|---|
Fuel Capacity | 94.6 litres | 113.5 litres |
Expedition 4x4 [L] | Expedition MAX 4x4 [L] | |
---|---|---|
Fuel Capacity | 94.6 litres | 113.5 litres |
Expedition 4x4 [kg.] | Expedition MAX 4x4 [kg.] | |
---|---|---|
Estimated Base Curb Weight | 2551 | 2628 |
Seating: |
||
Maximum Seating Capacity | 8 | 8 |
Expedition 4x4 [kg.] | Expedition MAX 4x4 [kg.] | |
---|---|---|
Estimated Base Curb Weight | 2551 | 2628 |
Seating: |
||
Maximum Seating Capacity | 8 | 8 |
Expedition 4x4 | Expedition MAX 4x4 | |
---|---|---|
Drive type | Control Trac® 4-wheel drive | Control Trac® 4-wheel drive |
Engine type | 3.5L EcoBoost® V6 | 3.5L EcoBoost® V6 |
Transmission | 10-speed automatic with SelectShift® | 10-speed automatic with SelectShift® |
Final drive ratio | 3.31 (non-limited slip standard); 3.73 (limited slip optional) |
3.73 (limited slip available) |
Fuel consumption |
13.8 L/100 km city, 10.7 L/100 km hwy, 12.4 L/100 km combined* | 14.9 L/100 km city, 11.2 L/100 km hwy, 13.2 L/100 km combined* |
Horsepower (SAE net @rpm) |
400 @ 5,000 | 400 @ 5,000 |
Torque (lb.-ft. @rpm) | 380 @ 2,250 |
380 @ 2,250 |
Compression ratio |
10.0:1 | 10.0:1 |
Valvetrain |
Twin independent Variable Camshaft Timing |
Twin independent Variable Camshaft Timing |
(Ti-VCT) |
(Ti-VCT) |
|
Fuel delivery | Gasoline Direct-injection | Gasoline Direct-injection |
Technology | Twin Turbochargers | Twin Turbochargers |
Exhaust | Single, stainless steel | Single, stainless steel |
Engine block type | Die-cast aluminum | Die-cast aluminum |
Cylinder head material | Aluminum alloy | Aluminum alloy |
*Fuel consumption ratings based on Transport Canada approved test methods. Actual fuel consumption will vary. |
Expedition 4x4 (XLT, Limited) |
Expedition 4x4 (Platinum) |
Expedition MAX 4x4 (Limited) |
Expedition MAX 4x4 (Platinum) |
|
---|---|---|---|---|
Drive type | Control Trac® 4-wheel drive |
Control Trac® 4-wheel drive |
Control Trac® 4-wheel drive | Control Trac® 4-wheel drive |
Engine type | 3.5L EcoBoost® V6 | 3.5L EcoBoost® V6 |
3.5L EcoBoost® V6 | 3.5L EcoBoost® V6 |
Transmission | 10-speed automatic with SelectShift® | 10-speed automatic with SelectShift® |
10-speed automatic with SelectShift® | 10-speed automatic with SelectShift® |
Final drive ratio | 3.31 Non-Limited-Slip, Standard 3.73 Limited-Slip, Optional |
3.31 Non-Limited-Slip, Standard 3.73 Limited-Slip, Optional |
3.31 Non-Limited-Slip, Standard 3.73 Limited-Slip, Optional |
3.31 Non-Limited-Slip, Standard 3.73 Limited-Slip, Optional |
Fuel consumption |
13.8 L/100 km city, 10.7 L/100 km hwy, 12.4 L/100 km combined* | 13.8 L/100 km city, 10.7 L/100 km hwy, 12.4 L/100 km combined* |
14.9 L/100 km city, 11.2 L/100 km hwy, 13.2 L/100 km combined* | 14.9 L/100 km city, 11.2 L/100 km hwy, 13.2 L/100 km combined* |
Horsepower (SAE net @rpm) |
375 @ 5,000 |
400 @ 5,000 |
375 @ 5,000 |
400 @ 5,000 |
Torque (lb.-ft. @rpm) | 470 @ 3,500 |
480 @ 3,250 |
470 @ 3,500 |
480 @ 3,250 |
Compression ratio |
10.0:1 | 10.0:1 |
10.0:1 | 10.0:1 |
Valvetrain |
Twin independent Variable Camshaft Timing |
Twin independent Variable Camshaft Timing |
Twin independent Variable Camshaft Timing |
Twin independent Variable Camshaft Timing |
(Ti-VCT) |
(Ti-VCT) |
(Ti-VCT) |
(Ti-VCT) |
|
Fuel delivery | Gasoline Direct-injection | Gasoline Direct-injection |
Gasoline Direct-injection | Gasoline Direct-injection |
Technology | Twin Turbochargers | Twin Turbochargers |
Twin Turbochargers | Twin Turbochargers |
Exhaust | Single, stainless steel | Twin Turbochargers |
Single, stainless steel | Single, stainless steel |
Engine block type | Die-cast aluminum | Die-cast aluminum |
Die-cast aluminum | Die-cast aluminum |
Cylinder head material | Aluminum alloy |
Die-cast aluminum |
Aluminum alloy | Aluminum alloy |
*Fuel consumption ratings based on Transport Canada approved test methods. Actual fuel consumption will vary. |
Front suspension | Independent Short- and Long-Arm (SLA) coil-over-shocks with stabilizer bar | Independent Short- and Long-Arm (SLA) coil-over-shocks with stabilizer bar |
Front shocks | Gas charged | Gas charged |
Rear suspension | Independent multi-link with stabilizer bar (mechanical load-levelling rear suspension available) | Independent multi-link with stabilizer bar (mechanical load-levelling rear suspension available) |
Rear shocks | Gas charged | Gas charged |
Brakes | Power 4-wheel disc Anti-Lock Brake System with brake assist and Electronic Brake Force Distribution | Power 4-wheel disc Anti-Lock Brake System with brake assist and Electronic Brake Force Distribution |
Steering | Electronic Power-Assist (EPAS) rack-and-pinion steering | Electronic Power-Assist (EPAS) rack-and-pinion steering |
Front suspension | Independent Short- and Long-Arm (SLA) coil-over-shocks with stabilizer bar | Independent Short- and Long-Arm (SLA) coil-over-shocks with stabilizer bar |
Front shocks | Gas charged | Gas charged |
Rear suspension | Independent multi-link with stabilizer bar (mechanical load-levelling rear suspension available) | Independent multi-link with stabilizer bar (mechanical load-levelling rear suspension available) |
Rear shocks | Gas charged | Gas charged |
Brakes | Power 4-wheel disc Anti-Lock Brake System with brake assist and Electronic Brake Force Distribution | Power 4-wheel disc Anti-Lock Brake System with brake assist and Electronic Brake Force Distribution |
Steering | Electronic Power-Assist (EPAS) rack-and-pinion steering | Electronic Power-Assist (EPAS) rack-and-pinion steering |
Maximum Loaded Trailer Weight | ||||
Axle Ratio | Axle Ratio | GCWR (kg) |
4x4 (kg) |
|
Model | Non-limited Slip | Limited Slip | ||
Non-MAX | 3.31 | 3.73 | 6804 |
4173 |
MAX | - | 3.73 | 6804 | 4082 |
Maximum Loaded Trailer Weight | ||||
Axle Ratio | Axle Ratio | GCWR (kg) |
4x4 (kg) |
|
Model | Non-limited Slip | Limited Slip | ||
Non-MAX | 3.31 | 3.73 | 6804 |
4173 |
MAX | - | 3.73 | 6804 | 4082 |
Expedition 4x4 | Expedition MAX 4x4 | |
---|---|---|
Engine Type |
3.5L EcoBoost® V6 with Ti-VCT |
3.5L EcoBoost® V6 with Ti-VCT |
Fuel consumption | 13.8 L/100 km city, 10.7 L/100 km hwy, 12.4 L/100 km combined* |
14.9 L/100 km city, 11.2 L/100 km hwy, 13.2 L/100 km combined* |
*Fuel consumption ratings based on Transport Canada approved test methods. Actual fuel consumption will vary. |
Expedition 4x4 | Expedition MAX 4x4 | |
---|---|---|
Engine Type |
3.5L EcoBoost® V6 with Ti-VCT |
3.5L EcoBoost® V6 with Ti-VCT |
Fuel consumption | 13.8 L/100 km city, 10.7 L/100 km hwy, 12.4 L/100 km combined* |
14.9 L/100 km city, 11.2 L/100 km hwy, 13.2 L/100 km combined* |
*Fuel consumption ratings based on Transport Canada approved test methods. Actual fuel consumption will vary. |
Max Seating Capacity | 8 |
Drive (System, Type of Train) | Control Trac® 4-wheel drive |
Transmissions | 6-speed automatic with SelectShift® |
Wheelbase | Expedition 4x4 - 3,022 mm. |
Expedition MAX 4x4 - 3,327 mm. | |
Maximum Towing Capacity | Non-MAX 4x4 - 4,173 kg. |
MAX 4x4 - 4082 kg. | |
Wheels Available | 18-inch bright machined-aluminum |
20-inch machined aluminum with Magnetic painted windows | |
20-inch polished aluminum (Limited) |
|
20-inch magnetic painted wheel (Limited) | |
20-inch polished aluminum (Platinum) | |
22-inch polished aluminum (Platinum) |
|
Warranty | Basic: 3 years/60,000 km |
Corrosion (Perforation Only): 5 years/unlimited km | |
Powertrain: 5 years/100,000 km | |
Safety Restraint System: 5 years/100,000 km | |
Roadside Assistance Program: 5 years/100,000 km |
Max Seating Capacity | 8 |
Drive (System, Type of Train) | Control Trac® 4-wheel drive |
Transmissions | 6-speed automatic with SelectShift® |
Wheelbase | Expedition 4x4 - 3,022 mm. |
Expedition MAX 4x4 - 3,327 mm. | |
Maximum Towing Capacity | Non-MAX 4x4 - 4,173 kg. |
MAX 4x4 - 4082 kg. | |
Wheels Available | 18-inch bright machined-aluminum |
20-inch machined aluminum with Magnetic painted windows | |
20-inch polished aluminum (Limited) |
|
20-inch magnetic painted wheel (Limited) | |
20-inch polished aluminum (Platinum) | |
22-inch polished aluminum (Platinum) |
|
Warranty | Basic: 3 years/60,000 km |
Corrosion (Perforation Only): 5 years/unlimited km | |
Powertrain: 5 years/100,000 km | |
Safety Restraint System: 5 years/100,000 km | |
Roadside Assistance Program: 5 years/100,000 km |
