Handling
Standard
- Hill Descent Control™
- Terrain Management System™
- Intelligent 4WD
- Trailer Sway Control
- 3.31 Non-Limited Slip Rear Axle
Optional
- Auto Start-Stop Removal
13.4/9.8
2132 L
Exterior Dimensions | |||
---|---|---|---|
Explorer XLT/ST-Line/Limited/Platinum (mm) | Explorer ST (mm) | Explorer Timberline (mm) | |
Wheelbase | 3,025 | 3,025 | 3,025 |
Length (ST has Unique front facia) | 5,049 | 5,063 | 5,049 |
Height | 1,782 | 1,782 | 1,782 |
Width - Excluding Mirrors | 2,004 | 2,004 | 2,004 |
Width - Including Mirrors | 2,268 | 2,268 | 2,268 |
Width - Mirrors Folded | 2,099 | 2,099 | 2,099 |
Front Track | 1,700 | 1,700 | 1,700 |
Rear Track | 1,700 | 1,700 | 1,700 |
Front Overhang (ST has unique front fascia) | 855 | 860 | 855 |
Rear Overhang | 1,169 | 1,169 | 1,169 |
Approach Angle (degrees) | 533 | 533 | 597 |
Departure Angle (degrees) | 558 | 558 | 602 |
Ramp Breakover Angle (degrees) | 434 | 434 | 434 |
Minimum Running Ground Clearance | 200 | 200 | 221 |
Exterior Dimensions | |||
---|---|---|---|
Explorer XLT/ST-Line/Limited/Platinum (in.) | Explorer ST (in.) | Explorer Timberline (in.) | |
Wheelbase | 119.1 | 119.1 | 119.1 |
Length (ST has Unique front facia) | 198.8 | 128.6 | 198.8 |
Height | 69.9 | 69.9 | 69.9 |
Width - Excluding Mirrors | 78.9 | 78.9 | 78.9 |
Width - Including Mirrors | 89.3 | 89.3 | 89.3 |
Width - Mirrors Folded | 82.7 | 82.7 | 82.7 |
Front Track | 66.9 | 66.9 | 66.9 |
Rear Track | 66.9 | 66.9 | 66.9 |
Front Overhang (ST has unique front fascia) | 33.7 | 33.8 | 33.7 |
Rear Overhang | 46.9 | 46.9 | 46.9 |
Approach Angle (degrees) | 21.0 | 22.0 | 23.5 |
Departure Angle (degrees) | 22.0 | 22.0 | 23.7 |
Ramp Breakover Angle (degrees) | 17.1 | 17.1 | 17.1 |
Minimum Running Ground Clearance | 7.9 | 8.2 | 8.7 |
Interior Dimensions | ||
---|---|---|
Explorer XLT/ST-Line/Limited/ST (mm) | Explorer Platinum (mm) | |
Head Room - First Row (Platinum is equipped with moonroof) | 1,035 | 987 |
Head Room - Second Row (Platinum is equipped with moonroof) | 1,028 | 971 |
Head Room - Third Row | 988 | 988 |
Maximum Leg Room - First Row | 1,093 | 1,093 |
Leg Room - Second Row | 991 | 991 |
Leg Room - Third Row | 817 | 817 |
Hip Room - First Row | 1,504 | 1,504 |
Hip Room - Second Row | 1,501 | 1,501 |
Hip Room - Third Row | 1,038 | 1,038 |
Shoulder Room - First Row | 1,570 | 1,570 |
Shoulder Room - Second Row | 1,573 | 1,573 |
Shoulder Room - Third Row | 1,388 | 1,388 |
Interior Dimensions | ||
---|---|---|
Explorer XLT/ST-Line/Limited/ST (in.) | Explorer Platinum (in.) | |
Head Room - First Row (Platinum is equipped with moonroof) | 40.7 | 38.9 |
Head Room - Second Row (Platinum is equipped with moonroof) | 40.5 | 38.2 |
Head Room - Third Row | 38.9 | 38.9 |
Maximum Leg Room - First Row | 43 | 43 |
Leg Room - Second Row | 39 | 39 |
Leg Room - Third Row | 32.2 | 32.2 |
Hip Room - First Row | 59.2 | 59.2 |
Hip Room - Second Row | 59.1 | 59.1 |
Hip Room - Third Row | 40.9 | 40.9 |
Shoulder Room - First Row | 61.8 | 61.8 |
Shoulder Room - Second Row | 61.9 | 61.9 |
Shoulder Room - Third Row | 54.6 | 54.6 |
Capacities | ||
---|---|---|
Explorer EcoBoost® (L - unless otherwise noted) | Explorer Hybrid (L - unless otherwise noted) | |
Maximum Seating Capacity (occupants) | 7 | 7 |
Passenger Volume | 4,322.8 | 4,322.8 |
Cargo Volume Behind 3rd Row | 528 | 528 |
Cargo Volume Behind 2nd Row | 1,264 | 1,264 |
Cargo Volume Behind 1st Row | 2,132 | 2,132 |
Fuel capacity | 70.4 L | 68.1 L |
Base Curb Weight | 2,022 kg | 2,253.9 kg |
Capacities | ||
---|---|---|
Explorer EcoBoost® (cu.ft. - unless otherwise noted) | Explorer Hybrid (cu.ft. - unless otherwise noted) | |
Maximum Seating Capacity (occupants) | 7 | 7 |
Passenger Volume | 152.7 | 152.7 |
Cargo Volume Behind 3rd Row | 18.2 | 18.2 |
Cargo Volume Behind 2nd Row | 47.9 | 47.9 |
Cargo Volume Behind 1st Row | 87.8 | 87.8 |
Fuel capacity | 18.6 U.S. gal | 18 U.S. gal |
Base Curb Weight | 4,345 | 4,969 |
Engine Specifications | |||
---|---|---|---|
2.3L EcoBoost® I-4 | 3.0L EcoBoost® V6 | 3.3L Hybrid | |
Drive type | Intelligent 4WD | Intelligent 4WD | Intelligent 4WD |
Engine type | 2.3L Turbocharged, Direct Injection Ti-VCT EcoBoost® I-4 | 3.0L twin-turbocharged EcoBoost® V6 | Naturally aspirated V6 |
Transmission | 10-speed automatic with selectShift® capability | 10-speed automatic with selectShift® capability | 10-speed automatic with selectShift® capability |
Final drive ratio | 3.58:1 | 3.31:1 | 3.58:1 |
Horsepower (net @ RPM) | 300 @ 5,500 rpm* | 365/400 @ 5,500 rpm* Platinum/ST | 318 @ 6,500 rpm** |
Torque (lb.-ft. @ RPM) | 310 @ 3,500 rpm* | 380/415 @ 3,500 rpm* | 322 @ 3,000 rpm** |
Compression ratio | 10.0:2 | 9.5: 1 | 12.0:1 |
Valve lifters | Direct acting mechanical bucket | Direct acting mechanical bucket | Direct acting mechanical bucket |
Induction System | Turbocharged | Twin Turbocharged | Naturally aspirated V6 |
Fuel delivery | Direct Injection | Direct Injection | Direct injection |
Exhaust | Dual exhaust with chrome tips | Dual exhaust with chrome tips | Dual exhaust with chrome tips |
Engine block type | Cast aluminum | Cast aluminum | Cast aluminum |
Cylinder head material | Cast aluminum | Cast aluminum | Cast aluminum |
Fuel Economy | With Stop-Start: 11.6 L/100km city, 8.7 L/100km highway, 10.3 L/100km combined† Without Stop-Start: 12.0 L/100km city, 9.0 L/100km highway, 10.7 L/100km combined† |
13.4 L/100km city, 9.8 L/100km highway, 11.8 L/100km combined† Without Stop-Start: 13.9 L/100km city, 9.7 L/100km highway, 12.0 L/100km combined† |
10.1 L/100km city, 9.1 L/100km highway, 9.6 L/100km combined† |
*Rating achieved using premium fuel. | |||
**Calculated via combined performance of the engine and electric motor(s) with peak battery power. The calculations utilize SAE J1349® engine results and Ford electric motor dyno testing. Your results may vary. | |||
†Fuel consumption ratings based on Government of Canada approved test methods. Actual fuel consumption will vary. |
Engine Specifications | |||
---|---|---|---|
2.3L EcoBoost® I-4 | 3.0L EcoBoost® V6 | 3.3L Hybrid | |
Drive type | Intelligent 4WD | Intelligent 4WD | Intelligent 4WD |
Engine type | 2.3L Turbocharged, Direct Injection Ti-VCT EcoBoost® I-4 | 3.0L twin-turbocharged EcoBoost® V6 | Naturally aspirated V6 |
Transmission | 10-speed automatic with selectShift® capability | 10-speed automatic with selectShift® capability | 10-speed automatic with selectShift® capability |
Final drive ratio | 3.58:1 | 3.31:1 | 3.58:1 |
Horsepower (net @ RPM) | 300 @ 5,500 rpm* | 365/400 @ 5,500* Platinum/ST | 318 @ 6,500 rpm** |
Torque (lb.-ft. @ RPM) | 310 @ 3,500 rpm* | 380/415 @ 3,500 rpm* | 322 @ 3,000 rpm** |
Compression ratio | 10.0:2 | 9.5: 1 | 12.0:1 |
Valve lifters | Direct acting mechanical bucket | Direct acting mechanical bucket | Direct acting mechanical bucket |
Induction System | Turbocharged | Twin Turbocharged | Naturally aspirated V6 |
Fuel delivery | Direct Injection | Direct Injection | Direct injection |
Exhaust | Dual exhaust with chrome tips | Dual exhaust with chrome tips | Dual exhaust with chrome tips |
Engine block type | Cast aluminum | Cast aluminum | Cast aluminum |
Cylinder head material | Cast aluminum | Cast aluminum | Cast aluminum |
Fuel Economy | With Stop-Start: : 20 MPG city / 27 MPG hwy / 23 MPG combined† Without Stop-Start: : 20 MPG city / 26 MPG hwy / 22 MPG combined† |
With Stop-Start: : 18 MPG city / 24 MPG hwy / 24 MPG combined† Without Stop-Start: : 17 MPG city / 24 MPG hwy / 20 MPG combined† |
23 MPG city / 26 MPG hwy / 25 MPG combined† |
*Rating achieved using premium fuel. | |||
**Calculated via combined performance of the engine and electric motor(s) with peak battery power. The calculations utilize SAE J1349® engine results and Ford electric motor dyno testing. Your results may vary. | |||
†Fuel consumption ratings based on Government of Canada approved test methods. Actual fuel consumption will vary. |
Chassis Specifications | |
---|---|
Front suspension | MacPherson strut front suspension with 32mm front stabilizer bar |
Front shocks | Gas-pressurized hydraulic |
Rear suspension | Multi-link independent rear suspension with 22mm rear stabilizer bar |
Rear shocks | Gas-pressurized hydraulic |
Brakes | Power 4-wheel disc with Anti-lock Braking System (ABS) |
Steering | Electronic Power-Assisted Steering (EPAS) |
Chassis Specifications | |
---|---|
Front suspension | MacPherson strut front suspension with 32mm front stabilizer bar |
Front shocks | Gas-pressurized hydraulic |
Rear suspension | Multi-link independent rear suspension with 22mm rear stabilizer bar |
Rear shocks | Gas-pressurized hydraulic |
Brakes | Power 4-wheel disc with Anti-lock Braking System (ABS) |
Steering | Electronic Power-Assisted Steering (EPAS) |
Towing Specifications | ||
---|---|---|
Configuration | Axle Ratio | Max. Loaded Trailer Weight |
2.3L EcoBoost® I-4 4WD | 3.58:1 | 2,404 kg |
3.0L EcoBoost® V6 4WD ST | 3.58:1 | 2,540 kg |
3.0L EcoBoost® V6 4WD (Non-ST) | 3.31:1 | 2,540 kg |
3.3L Hybrid V6 4WD | 3.73:1 | 2,268 kg |
Towing Specifications | ||
---|---|---|
Configuration | Axle Ratio | Max. Loaded Trailer Weight |
2.3L EcoBoost® I-4 4WD | 3.58:1 | 5,300 lbs. |
3.0L EcoBoost® V6 4WD ST | 3.58:1 | 5,600 lbs. |
3.0L EcoBoost® V6 4WD (Non-ST) | 3.31:1 | 5,600 lbs. |
3.3L Hybrid V6 4WD | 3.73:1 | 5,000 lbs. |
Fuel Consumption and Engine Highlights | |||
---|---|---|---|
Engine type | 2.3L EcoBoost® I-4 | 3.0L EcoBoost® V6 | 3.3L Hybrid |
Fuel Economy | With Stop-Start: 11.6 L/100km city, 8.7 L/100km highway, 10.3 L/100km combined† Without Stop-Start: 12.0 L/100km city, 9.0 L/100km highway, 10.7 L/100km combined† |
13.4 L/100km city, 9.8 L/100km highway, 11.8 L/100km combined† Without Stop-Start: 13.9 L/100km city, 9.7 L/100km highway, 12.0 L/100km combined† |
10.1 L/100km city, 9.1 L/100km highway, 9.6 L/100km combined† |
†Fuel consumption ratings based on Government of Canada approved test methods. Actual fuel consumption will vary. | |||
Vehicle Highlights | |||
Max Seating Capacity | 7 | ||
Warranty | Basic: 3 years/60,000 km | ||
Powertrain: 5 years/100,000 km | |||
Safety Restraint System: 5 years/100,000 km | |||
Corrosion (Perforation Only): 5 years/unlimited distance | |||
Roadside Assistance: 5 years/100,000 km | |||
Warranty (hybrid powertrain) | Your vehicle’s unique hybrid/electric components are covered during the Hybrid/Electric Unique Component Coverage, which lasts for 8 years or 100,000 miles, whichever occurs first. |
Fuel Consumption and Engine Highlights | |||
---|---|---|---|
Engine type | 2.3L EcoBoost® I-4 | 3.0L EcoBoost® V6 | 3.3L Hybrid |
Fuel Economy | With Stop-Start: : 20 MPG city / 27 MPG hwy / 23 MPG combined† Without Stop-Start: : 20 MPG city / 26 MPG hwy / 22 MPG combined† |
With Stop-Start: : 18 MPG city / 24 MPG hwy / 24 MPG combined† Without Stop-Start: : 17 MPG city / 24 MPG hwy / 20 MPG combined† |
23 MPG city / 26 MPG hwy / 25 MPG combined† |
†Fuel consumption ratings based on Government of Canada approved test methods. Actual fuel consumption will vary. | |||
Vehicle Highlights | |||
Max Seating Capacity | 7 | ||
Warranty | Basic: 3 years/36,000 miles | ||
Powertrain: 5 years/60,000 miles | |||
Safety Restraint System: 5 years/60,000 miles | |||
Corrosion (Perforation Only): 5 years/Unlimited miles | |||
Roadside Assistance Program: 5 years/60,000 miles | |||
Warranty (hybrid powertrain) | Your vehicle’s unique hybrid/electric components are covered during the Hybrid/Electric Unique Component Coverage, which lasts for 8 years or 100,000 miles, whichever occurs first. |
