What is the maximum available towing capacity of the 2026 Ford Super Duty® truck?

40,000 lbs maximum available gooseneck towing capacity 35,000 lbs maximum available 5th wheel towing capacity 30,000 lbs maximum available conventional towing capacity

What is the maximum available payload of the 2026 Ford Super Duty?

8,000 lbs maximum available gas payload 6,952 lbs maximum available diesel payload

How much does the 2026 Ford Super Duty weigh?

Weight varies based on vehicle configuration and accessories. Depending on configuration, Base Curb Weight ranges from 5,697 lbs to 8,627 lbs. Go to "Specs" to browse all configuration weights.

What engine options are available for the 2026 Ford Super Duty?

6.8L 2V DEVCT NA PFI V8 gas engine 7.3L 2V DEVCT NA PFI gas engine 6.7L 4V OHV Power Stroke® V8 Turbo Diesel B20 engine 6.7L High Output Power Stroke® V8 Turbo Diesel B20 engine

What is the difference between the F-350® dual rear wheel and the F-450® dual rear wheel?

The F-450 series generally offers greater towing capacity than the F-350, especially for gooseneck and 5th wheel towing. While the F-450 is designed with components for extreme hauling and enhanced durability (wider front axle and larger 19.5-inch wheels), certain configurations of the F-350 — particularly those with dual rear wheel and gas engines — can actually offer a higher payload capacity. Choosing between single and dually often comes down to your individual trucking needs.

What are the key differences between dual rear wheel and single rear wheel?

Single rear wheel (SRW) has one wheel on each side of the rear axle. This option is best suited for light to moderate towing and everyday driving, as it offers better manoeuvrability. Dual rear wheel (DRW) has two wheels on each side of the rear axle. This option is ideal for heavy-duty towing and hauling due to its greater stability, higher towing and payload capacity, and improved weight distribution.

2026 Ford Super Duty® Truck | Pricing, Photos, Specs & More

Fuel Capacity	109 Litre
	128 Litre
	182 Litre
Drive Type	4x2
	4x4
Available Engines	6.8L 2V DEVCT NA PFI V8 Gas
	7.3L 2V DEVCT NA PFI V8 Gas
	6.7L 4V OHV Power Stroke® V8 Turbo Diesel B20 engine
	6.7L High Output Power Stroke® V8 Turbo Diesel B20 engine
	HP = 405 @ 5,000 rpm \| TQ = 445 @ 4,000 rpm (6.8L Gas V8)
	HP = 430 @ 5,500 rpm \| TQ = 485 @ 4,000 rpm (7.3L Gas V8)
	HP = 475 @ 2,600 rpm \| TQ = 1,050 @ 1,600 rpm (6.7L Power Stroke® Turbo Diesel)
	HP = 500 @ 2,600 rpm \| TQ = 1,200 @ 1,600 rpm (6.7L HO Power Stroke® Turbo Diesel)
Transmission	TorqShift® G 10-speed SelectShift Automatic®
	TorqShift® 10-speed SelectShift Automatic® with Selectable Drive Modes
Wheelbase	141.4 (Regular Cab)
	147.8" (SWB SuperCab); 164.1" (LWB SuperCab)
	159.7" (SWB Crew Cab); 175.9" (LWB Crew Cab)
Warranty	Bumper to Bumper: 3 years / 60,000 km
	Powertrain: 5 years / 100,000 km; Diesel: 5 years / 160,000 km
	Safety Restraint System: 5 years / 100,000 km
	Corrosion (Perforation only): 5 years / Unlimited km
	Roadside Assistance Program: 5 years / 100,000 km

	Regular Cab	Regular Cab	SuperCab	SuperCab	SuperCab	SuperCab	Crew Cab	Crew Cab	Crew Cab	Crew Cab
SWB = short wheelbase (6 3/4' cargo box).	LWB	LWB	SWB	SWB	LWB	LWB	SWB	SWB	LWB	LWB
LWB = long wheelbase (8' cargo box).	4x2	4x4	4x2	4x4	4x2	4x4	4x2	4x4	4x2	4x4
	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm
Wheelbase	3,592	3,594	3,754	3,756	4,168	4,168	4,056	4,056	4,468	4,468
Length - overall	5,888	5,888	6,050	6,050	6,462	6,462	6,351	6,351	6,762	6,762
Height - F-250 SRW (w/o options)	2,005	2,068	2,014	2,070	2,009	2,070	2,013	2,073	2,007	2,068
Height - F-350 SRW (w/o options)	2,002	2,065	2,014	2,068	2,007	2,065	2,012	2,068	2,004	2,062
Height - F-350 DRW (w/o options)	2,017	2,065	-	-	2,009	2,068	-	-	2,019	2,070
Height - F-450 DRW (w/o options)	2,083	2,083	-	-	-	-	-	-	2,086	2,085
Width - SRW w/o mirrors	2,031	2,031	2,032	2,032	2,031	2,031	2,031	2,031	2,031	2,031
Width - DRW w/o mirrors	2,438	2,438	-	-	2,438	2,438	-	-	2,438	2,438
Width - SRW/DRW with standard mirrors	2,689	2,689	2,690	2,690	2,689	2,689	2,689	2,689	2,689	2,689
Track - front - F-250 SRW	1,766	1,765	1,765	1,765	1,765	1,765	1,765	1,765	1,765	1,765
Track - front - F-350 SRW	1,766	1,765	1,765	1,765	1,765	1,765	1,765	1,765	1,765	1,765
Track - front - F-350 DRW	1,766	1,765	1,765	1,765	1,765	1,765	1,765	1,765	1,765	1,765
Track - front - F-450 DRW	1,956	1,956	-	-	-	-	-	-	1,901	1,901
Track - rear - F-250 SRW	1,706	1,706	1,707	1,707	1,706	1,706	1,706	1,706	1,706	1,706
Track - rear - F-350 SRW	1,706	1,706	1,707	1,707	1,706	1,706	1,706	1,706	1,706	1,706
Track - rear - F-350 DRW	1,880	1,880	-	-	1,880	1,880	-	-	1,880	1,880
Track - rear - F-450 DRW	1,880	1,880	-	-	-	-	-	-	1,880	1,880
Minimum running ground clearance - F-250 SRW	246	239	252	236	259	246	251	234	259	241
Minimum running ground clearance - F-350 SRW	246	236	252	238	259	269	257	231	259	239
Minimum running ground clearance - F-350 DRW	251	234	-	-	259	239		-	259	249
Minimum running ground clearance - F-450 DRW	256	256	-	-	-	3592	-		262	262
Overhang - front	971	973	970	973	971	973	971	973	971	973
Overhang - rear	1,326	1,270	1,326	1,270	1,326	1,270	1,326	1,270	1,326	1,270
Angle of departure - F-250 SRW	19.7	21.3	485	531	18.7	20.8	19.3	21.1	18.8°	20.8°
Angle of departure - F-350 SRW	19.4	21.1	480	528	18.5	20.6	19	20.9	18.7	20.6
Angle of departure - F-350 DRW	20.7	21.5	-	-	18.7	20.9	-	-	20	20.9
Angle of departure - F-450 DRW	21.6	21.5	-	-	-	-	-	-	20.8	20.8
Ramp breakover angle - F-250 SRW	20.3	24.7	495	592	20.7	21.9	18.5	21.9	17.3	20.5
Ramp breakover angle - F-350 SRW	19	21.1	490	589	18.3	21.7	18.4	21.7	17.2	20.3
Ramp breakover angle - F-350 DRW	20.7	21.5	-	-	22.7	21.8	-	-	17.4	20.7
Ramp breakover angle - F-450 DRW	25.4	25.4	-	-	-	-	-	-	20.7	20.7
Angle of approach - F-250 SRW	16.7	15.8	539	683	21.8	27.6	21.2	26.7	21.7	27.3
Angle of approach - F-350 SRW	16.6	15.7	536	394	17.4	16.2	21.5	26.6	21.8	27.2
Angle of approach - F-350 DRW	20.7	21.5	-	-	17.8	17.4°	-	-	21.7	27.7
Angle of approach - F-450 DRW	18.5	18.5	-	-	-	-	-	-	26.9	26.9
Open tailgate to Ground - F-250 SRW	927	956	914	945	904	941	897	968	893	935

	Regular Cab	SuperCab	Crew Cab
Front	mm	mm	mm
Head room	1,036	1,036	1,036
Shoulder room	1,694	1,694	1,694
Hip room	1,588	1,588	1,588
Max leg room	1,115	1,115	1,115

Rear	mm	mm	mm
Head room	-	1,024	1,026
Shoulder room	-	1,671	1,674
Hip room	-	1,643	1,643
Leg room	-	851	1,107

Volumes	L	L	L
Passenger - total	1,643	2,954	3,350
Cargo - behind first row	277	770	1,356

FRONT SUSPENSION	kg
Type	Independent twin I-Beam (narrow front track) with coil springs, shock absorbers, stabilizer bar (F-250/F-350 4x2)
	Mono beam (narrow front track) with coil springs, shock absorbers, stabilizer bar (F-250/F-350 4x4) Mono beam (wide front track) with coil springs, shock absorbers, stabilizer bar (F-450)
Max. Front GAWR	kg
	2,268 kg. (F-250 4x2)
	2,540 kg. (F-250 4x4)
	2,268 kg. (F-350 SRW 4x2)
	2,540 kg. (F-350 SRW 4x4)
	2,404 kg. (F-350 DRW 4x4)
	2,540 kg. (F-350 DRW 4x4)
	2,540 kg. (F-350 DRW 4x4)
	2,404 kg. (F-450 DRW 4x4)
Springs	Coil
Shock absorbers	Heavy-duty gas
Stabilizer bar	Standard

REAR SUSPENSION
Type	Solid axle
Max. Rear GAWR	2,876 kg. (F-250 4x2)
	2,876 kg. (F-250 4x4)
	3,279 kg. (F-350 SRW 4x2)
	3,075 kg. (F-350 SRW 4x4)
	4,672 kg. (F-350 DRW 4x2)
	4,491 kg. (F-350 DRW 4x4)
	4,491 kg. (F-450 DRW 4x2)
	4,491 kg. (F-450 DRW 4x4)
Springs	Leaf
Shock absorbers	Heavy-duty gas
Stabilizer bar	Standard on DRW pickup; optional in select packages on SRW pickup

STEERING
Assist	Power Hydraulic

BRAKES
Type	4-wheel vented-disc ABS (standard)
Front (rotor diametre)	363 mm (F-250/F-350)
	391 mm (F-450)
Rear (rotor diametre)	363 mm (F-250/F-350)
	400 mm (F-450)
