Handling
Standard
- Rear Parking Sensors
- Intelligent Adaptive Cruise Control with Stop-and-Go, Lane Centering and Speed Sign Recognition
- Intelligent All-Wheel Drive with AWD Disconnect
- Four-Wheel Disc Brakes with Anti-Lock Brake System (ABS)
2023 Escape® ST-Line Elite
Standard
10.2/7.6
Est. City/Hwy - L/100km
2
Seating for
5
Seating for
Key Features
360-Degree Camera with Split View
Have a clear view of the environment around your Escape®, with help from cameras on the front, sides and rear. You can even get a bird's-eye view.10*
...less
U.S. model shown.
*Camera only operates at speeds under six miles per hour.
SYNC® 476 with 13.2" LCD Capacitive Touchscreen
The 2023 Escape® puts technology to work for you. Including the standard voice-activated SYNC® 476 system with its Android Auto™110 and Apple CarPlay®111 compatible centre-stack touchscreen.
...less
U.S. model shown.
2.0L EcoBoost® Engine with Auto Start-Stop Technology
At any speed, the 2.0L EcoBoost® engine’s twin-scroll turbocharger delivers consistently smooth power.
...less
U.S. model shown.
Power and Handling
Power
Standard
- Electric Power-Assisted Steering (EPAS)
- Post-Collision Braking
- 2.0L EcoBoost® Engine with Auto Start-Stop Technology Open image overlay for 2.0L EcoBoost® Engine with Auto Start-Stop Technology
- 8-Speed Automatic Transmission
- Engine Block Heater
- Electric Parking Brake Open image overlay for Electric Parking Brake
Optional
- 2.5L iVCT Atkinson-Cycle I-4 Hybrid engine Open image overlay for 2.5L iVCT Atkinson-Cycle I-4 Hybrid engine
Wheels & Tires
Standard
- Mini Spare Wheel
Interior Features
Climate
Standard
- Dual-Zone Electronic Automatic Temperature Control Open image overlay for Dual-Zone Electronic Automatic Temperature Control
Comfort and Convenience
Standard
- Glove Box
- Overhead Console with Sunglasses Storage
- Centre Floor Console with Armrest
- Cup Holders, 8 Total
- Driver's Side Footrest
- Carpeted Floor Mats, 1st-Row and 2nd-Row
- Coat hooks (2), 2nd-Row
- Grab handles, Front Passenger, 2nd-Row (Two)
- Ice Blue® Instrument Panel Cluster Lighting
- Message Centre and trip computer
- 12.3'' Full Digital Instrument Cluster Open image overlay for 12.3'' Full Digital Instrument Cluster
- Wireless Charging Pad
- Compass
- 2nd-Row Dome Light
- Front Map Lights
- Auto-Dimming Rearview Mirror
- Flat Bottom Sport Style Heated Steering Wheel with red stitching
- Illuminated Visor Vanity Mirrors (Driver and Front Passenger)
- Rotary Gear Shift Dial Open image overlay for Rotary Gear Shift Dial
- Selectable Drive Modes
- Powerpoints – First Row – (1) USB-A and (1) USB-C
- Powerpoints – (2) Rear - Smart Charging USB Outlets on back of centre console
- Power Windows with One-Touch-Up/Down Front and Rear
- Autolamp (Automatic On/Off) with Headlamp Courtesy Delay
- Ambient Lighting
- Intelligent Access with Push-Button Start
- Universal Garage Door Opener
- Remote Start System
- Outside Temperature Display
- Centre Console with Convenient Media Bin
- Pre-Collision Assist With Automatic Emergency Braking (AEB), Pedestrian Detection, Forward Collision Warning and Dynamic Brake Support
- Lane-Keeping System (includes Lane-Keeping Assist, Lane-Keeping Alert and Driver Alert)
- BLIS® (Blind Spot Information System) With Cross-Traffic Alert Open image overlay for BLIS® (Blind Spot Information System) With Cross-Traffic Alert
- 360-Degree Camera with Split View Open image overlay for 360-Degree Camera with Split View
- Aluminum SVT Foot Pedal
- Sports Dark Headliner
Optional
- Floor Liners with Carpet Mats
- Floor Liners without Carpet Mats
- Easy Access Cargo Shade
- Panoramic Vista Roof® Open image overlay for Panoramic Vista Roof®
- Cargo Mat
Entertainment Systems
Standard
- AM/FM Stereo with 6 Speakers
- SYNC® 476 with 13.2" LCD Capacitive Touchscreen Open image overlay for SYNC® 476 with 13.2" LCD Capacitive Touchscreen
- Wireless Apple CarPlay® and Android Auto™ Compatibility
- FordPass Connect™112 (Wi-Fi Hotspot Capability124) Open image overlay for FordPass Connect™112 (Wi-Fi Hotspot Capability124)
- Connected Built-In Navigation (With 3 Years Of Service)134 Open image overlay for Connected Built-In Navigation (With 3 Years Of Service)134
- SiriusXM® 360L Open image overlay for SiriusXM® 360L
- Evasive Steering Assist
Optional
- B&O® Sound System by Bang & Olufsen®, 10-Speakers Including Subwoofer Open image overlay for B&O® Sound System by Bang & Olufsen®, 10-Speakers Including Subwoofer
Seating
Standard
- Driver's Seat and Driver/Front Passenger Sideview Mirrors with Memory
- Heated Front Row Seats Open image overlay for Heated Front Row Seats
- 10-Way Power Driver Seat
- 6-Way Power Passenger
- Map Pocket, Passenger Seat-Back
- 2nd-Row Sliding Seats, 60/40 Split-Fold Down Open image overlay for 2nd-Row Sliding Seats, 60/40 Split-Fold Down
- Partial Vinyl & Cloth seats with red stitching Open image overlay for Partial Vinyl & Cloth seats with red stitching
Optional
- Leather-Trimmed Seats with Quilting Design and Mini-Perforation
Exterior Features
Appearance
Standard
- Body Colour Door Handles
- Black Mesh Grille Open image overlay for Black Mesh Grille
- Coast to coast LED Lightbar Headlamps
- Daytime Running Lamps (DRL)
- Body-Colour large single wing rear spoiler
- Body Colour Sideview Mirror Caps
- Mirrors, Sideview - Heated Glass
- Black Upper Window Molding with Black Beltline Molding
- Dual Chrome Exhaust Tips Open image overlay for Dual Chrome Exhaust Tips
- Black Moulded-in-Colour Lower Bodyside Cladding
- Black Roof Rack Side Rails Open image overlay for Black Roof Rack Side Rails
- LED Fog Lamps
- 19” Machined-face Ebony-painted Aluminum Wheels Open image overlay for 19” Machined-face Ebony-painted Aluminum Wheels
Optional
- Roof Rack Crossbars
- 19" Unique Aluminum Wheels
Windows & Glass
Standard
- Privacy Glass - 2nd-Row Side and Liftgate
- Rear Fixed-Intermittent/Continuous Wiper/Washer
- Front Variable Intermittent/Continuous Wipers with Washer
- Rain-Sensing Wipers (front only) Open image overlay for Rain-Sensing Wipers (front only)
Safety
Safety
Standard
- Traction Control
- Curve Control Open image overlay for Curve Control
- Personal Safety System™ with Dual-Stage Driver and Front-Passenger Airbags
- Driver Knee Airbag
- Front seat-mounted side-impact airbags
- Safety Canopy® System Open image overlay for Safety Canopy® System
- Belt-Minder® (Front and 2nd-Row)
- Head Restraints
- Front Row Height Adjustable Retractable Safety Belts with Three-Point on all five (5) Seating Positions
- Lower Anchors and Tether Anchors for Children (LATCH)
- SOS Post-Crash Alert System™
- Tire Pressure Monitoring System (TPMS) Open image overlay for Tire Pressure Monitoring System (TPMS)
Security
Standard
- LED Reflector Headlamps with LED Signature Lighting Open image overlay for LED Reflector Headlamps with LED Signature Lighting
- Auto High-Beam Headlamps
- Rear View Camera Open image overlay for Rear View Camera
- Cargo Tie-Down Hooks– two (2), Grocery – two (2)
- Torque Vectoring Control Open image overlay for Torque Vectoring Control
- AdvanceTrac® with RSC® (Roll Stability Control™) Open image overlay for AdvanceTrac® with RSC® (Roll Stability Control™)
- SecuriLock® Passive Anti-Theft System
- Remote Keyless-Entry System - Key with Integrated Key FOB
- Perimeter alarm
- SecuriCode™ Keyless-Entry Keypad
- 360-Degree Digital Camera with Split View and Front/Rear Washer
Packages
Packages
Standard
- Ford Co-Pilot360™ Technology Open image overlay for Ford Co-Pilot360™ Technology
- Cold Weather Package Open image overlay for Cold Weather Package
Optional
- Class II Trailer Tow Package Open image overlay for Class II Trailer Tow Package
- Premium Technology Package Open image overlay for Premium Technology Package
Standard Features
Standard
- Equipment Group 501A
Optional
- Equipment Group 500A (Hybrid)
Specifications
Exterior
| Exterior Dimensions | |
|---|---|
| mm | |
| Wheelbase | 2,710 |
| Length | 4,585 |
| Vehicle height - without options | 1,679 |
| Vehicle width - including mirrors | 2,174 |
| Vehicle width - excluding mirrors | 1,882 |
| Vehicle width - mirrors folded | 1,999 |
| Front Track | 1,585 |
| Rear Track | 1,570 |
| Drive system | Front-Wheel Drive/All-Wheel Drive |
| Base Curb Weight | 2.5L iVCT - FWD Hybrid - 1,596 kg |
| 2.5L i-VCT Plug-in Hybrid - 1,671.9 kg | |
| 2.5L i-VCT Hybrid - 1,770.8 kg | |
| 1.5L EcoBoost® - FWD - 1,489 kg | |
| 1.5L EcoBoost® - AWD - 1,550.8 kg | |
| 2.0L Twin-Scroll EcoBoost® - AWD - 1,607 kg |
| Exterior Dimensions | |
|---|---|
| inches | |
| Wheelbase | 106.7 |
| Length | 180.1 |
| Vehicle height - without options | 66.1 |
| Vehicle width - including mirrors | 85.6 |
| Vehicle width - excluding mirrors | 74.1 |
| Vehicle width - mirrors folded | 78.7 |
| Front Track | 62.4 |
| Rear Track | 61.8 |
| Drive system | Front-Wheel Drive/All-Wheel Drive |
| Base Curb Weight | 2.5L iVCT - FWD Hybrid - ST-Line 3,519 lbs. |
| 2.5L i-VCT AWD Hybrid - ST-Line Plus 3,686 lbs. | |
| 2.5L i-VCT Plug-in Hybrid FWD - 3,904 lbs. | |
| 1.5L EcoBoost® - FWD - 3,283 lbs. | |
| 1.5L EcoBoost® - AWD - 3,419 lbs. | |
| 2.0L Twin-Scroll EcoBoost® - AWD- ST-Line Plus - 3,543 lbs. |
Interior
| Interior Dimensions | |
|---|---|
| mm | |
| Head room - First row | 1,016 |
| Head room - Second row | 998 |
| Leg room - First row (maximum) | 1,077 |
| Leg room - Second row | 1,035 |
| Leg room - Second row (Hybrid/Plug-in Models) | 989 |
| Hip room - First row | 1,402 |
| Hip room - Second row | 1,354 |
| Shoulder room - First row | 1,463 |
| Shoulder room - Second row | 1,422 |
| Interior Dimensions | |
|---|---|
| inches | |
| Head room - First row | 40 |
| Head room - Second row | 39.3 |
| Leg room - First row (maximum) | 42.4 |
| Leg room - Second row | 40.7 |
| Leg room - Second row (Hybrid/Plug-in Models) | 38.9 |
| Hip room - First row | 55.2 |
| Hip room - Second row | 53.3 |
| Shoulder room - First row | 57.6 |
| Shoulder room - Second row | 56 |
Capacities
| Capacities: Passengers, Luggage, Fuel | |
|---|---|
| Seating (max) capacity | 5 passengers |
| Passenger volume (1.5L/2.0L) | 2,945 L |
| Passenger volume (Hybrid/Plug-in Hybrid) | 2,894 L |
| Cargo volume behind first row (1.5L/2.0L) | 1,851.9 L |
| Cargo volume behind first row (Hybrid/Plug-in Hybrid) | 1,721.6 L |
| Cargo volume behind second row (maximum) (1.5L/2.0L) | 1,061.8 L |
| Cargo volume behind second row (maximum) (Hybrid/Plug-in Hybrid) | 974 L |
| Fuel Capacity (1.5L EcoBoost®) (FWD/AWD) | 56/59.4 L |
| Fuel Capacity (2.0L EcoBoost®) | 59.4 L |
| Fuel Capacity (2.5L FHEV) | 54.1 L |
| Fuel Capacity (2.5L PHEV) | 42 L |
| Capacities: Passengers, Luggage, Fuel | |
|---|---|
| Seating (max) capacity | 5 passengers |
| Passenger volume (1.5L/2.0L) | 104 cu. ft. |
| Passenger volume (Hybrid/Plug-in Hybrid) | 102.2 cu. ft. |
| Cargo volume behind first row (1.5L/2.0L) | 65.4 cu. ft. |
| Cargo volume behind first row (Hybrid/Plug-in Hybrid) | 60.8 cu. ft. |
| Cargo volume behind second row (maximum) (1.5L/2.0L) | 37.5 cu. ft. |
| Cargo volume behind second row (maximum) (Hybrid/Plug-in Hybrid) | 34.4 cu.ft |
| Fuel Capacity (1.5L EcoBoost®) (FWD/AWD) | 14.8/15.7 gallons |
| Fuel Capacity (2.0L EcoBoost®) | 15.7 gallons |
| Fuel Capacity (2.5L FHEV) | 14.3 gallons |
| Fuel Capacity (2.5L PHEV) | 11.1 gallons |
Engine
| Engine Specifications | ||||
|---|---|---|---|---|
| Engine type | 2.5L iVCT I-4 Hybrid | 2.5L iVCT I-4 Plug-in Hybrid | 1.5L EcoBoost® I-4 | 2.0L Twin-Scroll EcoBoost® I-4 |
| Drive type | Front-Wheel Drive (FWD) or Intelligent AWD with AWD Disconnect | Front-Wheel Drive (FWD) | Front-Wheel Drive (FWD) or optional Intelligent AWD | Intelligent AWD |
| Exhaust | Dual-Chrome Exhaust Tips | Dual-Chrome Exhaust Tips | Dual-Chrome Exhaust Tips | Dual-Chrome Exhaust Tips |
| Transmission type | Electronic Continuous Variable Transmission | Electronic Continuous Variable Transmission | 8-speed automatic | 8-speed Automatic Transmission with SelectShift® with Paddle shifters |
| Horsepower (SAE net @ rpm) | 163 @ 6,250 rpm** | 163 @ 6,250 rpm** | 180 @ 6,000 rpm* | 250 @ 5,500 rpm (premium fuel) |
| Torque (lb.-ft.@ rpm) | 155 @ 4,500 rpm** | 155 @ 4,500 rpm** | 199 @ 3,000 rpm* | 280 @ 3,000 rpm* |
| Total System Horsepower (Hybrid and Plug-in Hybrid) | 192** | 210** | - | - |
| Compression ratio | 13.0:1 | 13.0:1 | 11.0:1 | 10.8:1 |
| Valve lifters | Direct acting mechanical bucket | Direct acting mechanical bucket | Direct acting mechanical bucket | Roller finger follower |
| Engine block material | Aluminum | Aluminum | Aluminum | Aluminum |
| Cylinder head material | Aluminum | Aluminum | Aluminum | Aluminum |
| Induction system | Naturally aspirated | Naturally aspirated | Turbocharged | Turbocharged |
| Fuel delivery | Sequential multi-port electronic fuel injection | Sequential multi-port electronic fuel injection | Direct injection | Direct injection and port fuel injection |
| Fuel Economy | FWD: 5.6 L/100km city, 6.5 L/100km highway, 6.0 L/100km combined* AWD: 5.6 L/100km city, 6.5 L/100km highway, 6.0 L/100km combined* |
FWD: 2.3 Le/100km electricity + gasoline, 5.9 l/100km gasoline only* | FWD: 8.9 L/100km city, 6.9 L/100km highway, 8.0 L/100km combined* AWD: 9.2 L/100km city, 7.4 L/100km highway, 8.4 L/100km combined* |
AWD: 10.2 L/100km city, 7.6 L/100km highway, 9.1 L/100km combined* |
| *Fuel consumption ratings based on Government of Canada approved test methods. Actual fuel consumption will vary. |
| Engine Specifications | ||||
|---|---|---|---|---|
| Engine type | 2.5L iVCT I-4 Hybrid | 2.5L iVCT I-4 Plug-in Hybrid | 1.5L EcoBoost® I-4 | 2.0L Twin-Scroll EcoBoost® I-4 |
| Drive type | Front-Wheel Drive (FWD) or Intelligent AWD with AWD Disconnect | Front-Wheel Drive (FWD) | Front-Wheel Drive (FWD) or optional Intelligent AWD | Intelligent AWD |
| Exhaust | Dual-Chrome Exhaust Tips | Dual-Chrome Exhaust Tips | Dual-Chrome Exhaust Tips | Dual-Chrome Exhaust Tips |
| Transmission type | Electronic Continuous Variable Transmission | Electronic Continuous Variable Transmission | 8-speed automatic | 8-speed Automatic Transmission with SelectShift® with Paddle shifters |
| Horsepower (SAE net @ rpm) | 163 @ 6,250 rpm** | 163 @ 6,250 rpm** | 180 @ 6,000 rpm* | 250 @ 5,500 rpm (premium fuel) |
| Torque (lb.-ft.@ rpm) | 155 @ 4,500 rpm** | 155 @ 4,500 rpm** | 199 @ 3,000 rpm* | 280 @ 3,000 rpm* |
| Total System Horsepower (Hybrid and Plug-in Hybrid) | 192** | 210** | - | - |
| Compression ratio | 13.0:1 | 13.0:1 | 11.0:1 | 10.8:1 |
| Valve lifters | Direct acting mechanical bucket | Direct acting mechanical bucket | Direct acting mechanical bucket | Roller finger follower |
| Engine block material | Aluminum | Aluminum | Aluminum | Aluminum |
| Cylinder head material | Aluminum | Aluminum | Aluminum | Aluminum |
| Induction system | Naturally aspirated | Naturally aspirated | Turbocharged | Turbocharged |
| Fuel delivery | Sequential multi-port electronic fuel injection | Sequential multi-port electronic fuel injection | Direct injection | Direct injection and port fuel injection |
| Fuel Economy | FWD: 42 MPG city / 36 MPG hwy / 39 MPG combined* AWD: 42 MPG city / 36 MPG hwy / 39 MPG combined* |
FWD: 101 MPGe electricity + gasoline / 40 MPG city/hwy combined* | FWD: 27 MPG city / 34 MPG hwy / 30 MPG combined* AWD: 26 MPG city / 32 MPG hwy / 28 MPG combined* |
AWD: 23 MPG city / 31 MPG hwy / 26 MPG combined* |
| *Fuel consumption ratings based on Government of Canada approved test methods. Actual fuel consumption will vary. |
Chassis
| Chassis Specifications | |
|---|---|
| Front suspension | Independent MacPherson strut-type with stabilizer bar, twin-tube hydraulic gas-pressurized shocks |
| Rear suspension | Independent double lateral link semi-trailing arms with stabilizer bar, progressive-rate springs and hydraulic gas-pressurized shocks |
| Traction assist | AdvanceTrac® with RSC® (Roll Stability Control™) |
| Brakes | Power 4-wheel disc with Anti-Lock Brake System (ABS) |
| Steering | Electric power-assisted steering (EPAS) |
| Chassis Specifications | |
|---|---|
| Front suspension | Independent MacPherson strut-type with stabilizer bar, twin-tube hydraulic gas-pressurized shocks |
| Rear suspension | Independent double lateral link semi-trailing arms with stabilizer bar, progressive-rate springs and hydraulic gas-pressurized shocks |
| Traction assist | AdvanceTrac® with RSC® (Roll Stability Control™) |
| Brakes | Power 4-wheel disc with Anti-Lock Brake System (ABS) |
| Steering | Electric power-assisted steering (EPAS) |
Towing
| kg | |
|---|---|
| 2.5L ATK I-4 - FWD | 680 |
| 2.5L Plug-in Hybrid | 680 |
| 1.5L EcoBoost® - FWD | 907 |
| 1.5L EcoBoost® - AWD | 907 |
| 2.0L Twin-Scroll EcoBoost® I-4 - AWD | 1,587 |
| lbs | |
|---|---|
| 2.5L ATK I-4 - FWD | 1,500 |
| 2.5L Plug-in Hybrid | 1,500 |
| 1.5L EcoBoost® - FWD | 2,000 |
| 1.5L EcoBoost® - AWD | 2,000 |
| 2.0L Twin-Scroll EcoBoost® I-4 - AWD | 3,500 |
Highlights
| Fuel Consumption and Engine Highlights | |
|---|---|
| Escape FWD 1.5L | 8.9 L/100km city, 6.9 L/100km highway, 8.0 L/100km combined* |
| Escape FWD HEV 2.5L | 5.6 L/100km city, 6.5 L/100km highway, 6.0 L/100km combined* |
| Escape PHEV 2.5L | 2.3 Le/100km electricity + gasoline, 5.9 l/100km gasoline only* |
| Escape AWD 1.5L | 9.2 L/100km city, 7.4 L/100km highway, 8.4 L/100km combined* |
| Escape AWD 2.0L | 10.2 L/100km city, 7.6 L/100km highway, 9.1 L/100km combined* |
| Escape AWD HEV 2.5L | 5.6 L/100km city, 6.5 L/100km highway, 6.0 L/100km combined* |
| *Fuel consumption ratings based on Government of Canada approved test methods. Actual fuel consumption will vary. | |
| Vehicle Highlights | |
| Maximum Seating Capacity | 5 passengers |
| Drive Type | Front Wheel Drive or available Intelligent All-Wheel-Drive (not available on Plug-in Hybrid) |
| Transmission | 8-Speed Automatic (1.5 and 2.0L only) |
| Maximum Towing Capacity | 1,587 kg with 2.0L Twin-Scroll EcoBoost® I-4 and Class II Trailer Tow Package |
| Warranty | Basic: 3 years/60,000 km |
| Powertrain: 5 years/100,000 km | |
| Safety Restraint System: 5 years/100,000 km | |
| Corrosion (Perforation Only): 5 years/unlimited distance | |
| Roadside Assistance: 5 years/100,000 km |
| Fuel Consumption and Engine Highlights | |
|---|---|
| Escape FWD 1.5L | 27 MPG city / 34 MPG hwy / 30 MPG combined* |
| Escape FWD HEV 2.5L | 42 MPG city / 36 MPG hwy / 39 MPG combined* |
| Escape PHEV 2.5L | 101 MPGe electricity + gasoline / 40 MPG city/hwy combined* |
| Escape AWD 1.5L | 26 MPG city / 32 MPG hwy / 28 MPG combined* |
| Escape AWD 2.0L | 23 MPG city / 31 MPG hwy / 26 MPG combined* |
| Escape AWD HEV 2.5L | 42 MPG city / 36 MPG hwy / 39 MPG combined* |
| *Fuel consumption ratings based on Government of Canada approved test methods. Actual fuel consumption will vary. | |
| Vehicle Highlights | |
| Maximum Seating Capacity | 5 passengers |
| Drive Type | Front Wheel Drive or available Intelligent All-Wheel-Drive (not available on Plug-in Hybrid) |
| Transmission | 8-Speed Automatic (1.5 and 2.0L only) |
| Maximum Towing Capacity | 3,500 lbs. with 2.0L Twin-Scroll EcoBoost® - I-4 and Class II Trailer Tow Package |
| Warranty | Basic: 3 years/36,000 miles |
| Powertrain: 5 years/60,000 miles | |
| Safety Restraint System: 5 years/60,000 miles | |
| Corrosion (Perforation Only): 5 years/Unlimited miles | |
| Roadside Assistance Program: 5 years/60,000 miles |
